Address for special port - sets address of LPT port, if a Special port is selected.
Pressing key <Enter> or button OK initiates scanning for programmer by set parameters.
There is same activity as at start the control program. The command clears a list of default
devices without the current device, if the new selected programmer supports this one.
This setting is saved to disk by command Options / Save options.
Programmer / Refind programmer
This menu command is used to refind (reestablish communication with) currently selected
programmer.
To select other type of programmer, programmer communication parameters and to establish
communication with newly selected programmer use menu Programmer / Find
programmer.
Programmer / Handler
In dialog Handler a Handler type and Handler communication parameters can be set.
Handler is an external device for special control of device operations in control program.
When None Handler is selected, this means default state of control program, i.e. device
operations are controlled directly by user otherwise control program is in special mode, when
device operations are controlled automatically with co-operation with Handler.
Dialog Handler contains following items:
Selected Handler
Search at port
Pressing key <Enter> or button OK initiates scanning for Handler by set parameters. If
selected Handler type is None, no Handler scanning will be processed. Current Handler
settings are saved to configuration file by command Options / Save options or when control
program is closed.
Handler is not available for sale.
Programmer / Module options
This option is used for multiple socket programmers for defining MASTER socket and activity
of each socket. MASTER socket group box allows user to set socket which is preferentially
used for device reading operation. Enable/Disable socket checkbox array allows user to set
enabling and disabling of each socket individually. Disabled sockets are ignored for any
device operation.
Programmer / Automatic YES!
This command is used for setting Automatic YES! mode. In this mode you just take off the
programmed device, then put new device into ZIF socket and a last operation will be
repeated automatically. Program automatically detects an insertion of a new device and runs
last executed operation without pressing any key or button. An insertion of device into ZIF is
displayed on the screen. Repeated operation executing will be cancelled by pressing key
<ESC> during waiting for insert/remove a device to/from ZIF.
select wished Handler type.
select a COM port, which will be scanned for a requested Handler.
