ELNEC s. r. o.
User's Manual for
JetProg
Universal 48-pindrive Programmer,
expandable up to 256.
LabProg+
Universal 48-pindrive Programmer
PREPROM-02aLV
Universal Memory Programmer
51&AVRprog
MCS51 Series and Atmel AVR Microcontrollers
Programmer
PIKprog
Microchip PICmicro Programmer
SEEprog
Serial EEPROM Programmer
ELNEC s.r.o.
Presov, Slovakia
February 2001
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JetProg and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elnec JetProg

Summary of Contents for Elnec JetProg

  • Page 1 ELNEC s. r. o. User's Manual for JetProg Universal 48-pindrive Programmer, expandable up to 256. LabProg+ Universal 48-pindrive Programmer PREPROM-02aLV Universal Memory Programmer 51&AVRprog MCS51 Series and Atmel AVR Microcontrollers Programmer PIKprog Microchip PICmicro Programmer SEEprog Serial EEPROM Programmer ELNEC s.r.o.
  • Page 2 ELNEC s.r.o. assumes no responsibility for misuse of this manual. ELNEC s.r.o. reserves the right to make changes or improvements to the product described in this manual at any time without notice. This manual contains names of companies, software products, etc., which may be trademarks of their respective owners.

  • Page 3: How To Use This Manual

    User's Manual. Revisions are implemented in the context sensitive help before the printed Users Manual. Note: Because this user's manual is common for all ELNEC programmers, read please section(s) respective programmer you have bought.

  • Page 5: Table Of Contents

    How to use this manual..............3 Introduction ..................9 Products configuration ..............12 PC requirements.................13 Quick Start..................15 JetProg ..................17 Introduction.................18 JetProg elements................22 Connecting JetProg to the PC.............23 Selftest and Calibration...............25 Technical specification..............26 LabProg+ ..................31 Introduction.................32 LabProg+ elements ..............35 Connecting LabProg+ to the PC ..........36 Selftest and Calibration...............38 Technical specification..............39...
  • Page 6 ELNEC s. r. o. If you have an unsupported target device........110 Warranty terms .................111 Appendix..................113 Appendix A - Programmer Problem Report form .......115 Appendix B - Device Problem Report form ........117 Appendix C - Keep-Current Service ..........119 Appendix D - AlgOR service............121 Appendix E - registration card ...........123...
  • Page 7 ELNEC s. r. o. Conventions used in the manual References to the control program functions are in bold, e.g. Load, File, Device, etc. References to control keys are written in brackets <>, e.g. <F1>. Terminology used in the manual: Device...

  • Page 9: Introduction

    Introduction Introduction...
  • Page 10 SEEprog, 51&AVRprog, PIKprog and SEEprog. JetProg is a universal programmer and logic IC tester with 48 powerful pindrivers in base configuration, expandable up to 256. This design allows to easily add new devices to the device list. Provides very competitive price but excellent hardware design for reliable programming.
  • Page 11 We also offer the following new services in our customer support program: Keep-Current and AlgOR. • Keep-Current is a service by which ELNEC ships to you the latest version of the control program for programmer and the updated user documentation. A Keep-Current service is your hassle-free guarantee that you always have access to the latest software and documentation, at minimal cost.

  • Page 12: Products Configuration

    JetProg, LabProg+ and PREPROM-02aLV programmer configuration • programmer • cable with two 25 pin, D-type connectors for connecting the programmer to the PC •...

  • Page 13: Pc Requirements

    • HDD with minimum 10 MB free space • operating system: MS Windows 95/98/NT/2000 • one free bi-directional printer port with nothing attached • for JetProg free parallel (printer) port on PCI bus, IEEE 1284 compatible (ECP/EPP) Note: For convenience, we suggest that you use a...

  • Page 15: Quick Start

    Quick Start Quick Start...
  • Page 16 ELNEC s. r. o. Installing programmer hardware • switch off the PC and programmer • connect the communication port of programmer to a printer port of PC using cable supplied. • switch on the PC • connect the connector of the power supply adapter to the...

  • Page 17: Jetprog

    JetProg JetProg...

  • Page 18: Introduction

    Best "value for money" in this class. JetProg interfaces with the IBM PC, AT or higher, portable or desktop personal computers. Programmer allows you to directly connect to your PC through any standard parallel (printer) port (no special interface card needed).
  • Page 19 JetProg JetProg has 48 powerful pindrivers in base unit, expandable up to 256 pindrivers using "pindriver expansion" modules. Advanced pin drivers incorporate high-quality high-speed circuitry to deliver programming and testing performance without overshoot ground bounce device technologies. Pin drivers operate down to 1.8V so you'll be ready to program the full range of today's advanced low- voltage devices.
  • Page 20 PLCC, DIL to PSOP, DIL to SOIC, DIL to TQFP and DIL to TSOP. Software controlled pin-swapping capability together with universal converters are what give the JetProg the ability to program the target device in any package type. For...
  • Page 21 "adapters.txt" included with the control program. It is important to remember that in most cases new devices require only a software upgrade since the JetProg has 48 true pin drivers, which can perform as required under program control. With our prompt service new devices can be added to...

  • Page 22: Jetprog Elements

    "sleep mode". In this state it consumes less than 1W of power. Therefore the programmer has no On/Off switch. When the power LED indicator glows with a low intensity the JetProg is in sleep mode.

  • Page 23: Connecting Jetprog To The Pc

    Connecting JetProg to the PC Switch off PC and programmer. Insert the communication cable included with your JetProg programmer package to a free printer port on your PC. If your computer is equipped with only one printer port, substitute the programmer cable for the printer cable.
  • Page 24 • When disconnecting the programmer from the PC: FIRST disconnect the power-supply connector and THEN the communication cable. From JetProg's point of view the connecting and disconnecting sequence is irrelevant. Protection circuits on all programmer inputs keep it safe. But think of your PC please.

  • Page 25: Selftest And Calibration

    JetProg Selftest and Calibration If you feel that your programmer does not react according to your expectation, please run the programmer selftest using Diagnostic POD, enclosed with the standard delivery package. For optimal results with programmer we recommend you undertake every 6 months, an extended test and to check the calibration.

  • Page 26: Technical Specification

    ELNEC s. r. o. Technical specification HARDWARE Base unit, DACs • FPGA based IEEE 1284 slave printer port, up to 1MB/s transfer rate • on-board powerful microprocessor (20MHz) supported by FPGA based state machine, 20MHz powered • three D/A converters for VCCP, VPP1, and VPP2, controllable rise and fall time •...
  • Page 27 JetProg • Flash EPROM: 28Fxxx, 29Cxxx, 29Fxxx, 29BVxxx, 29LVxxx, 29Wxxx, 49Fxxx series, from 256Kbit to 32Mbit, with 8/16 bit data width, full support for LV series • serial E(E)PROM: 17Cxxx, 24Cxxx, 24Fxxx, 25Cxxx, 59Cxxx, 85xxx, 93Cxxx, NVM3060, MDAxxx series, full support for LV series •...
  • Page 28 ELNEC s. r. o. Programming speed Note. These times strongly depend on PC speed, LPT port type and operating system free resources. Therefore are given values of two different PC configurations for comparison. Device Operation Time A Time B 27C010...
  • Page 29 • temperature 5°..40°C • humidity 20%..80%, non condensing Base configuration package includes • JetProg, base unit • JetProg, DIL48 socket module • connection cable • diagnostic POD for selftest • anti-dust cover for ZIF socket • power supply adapter 220VAC/12VAC/12W (120VAC/12VAC/12W for 120VAC mains) •...
  • Page 30 ELNEC s. r. o. Additional services • Keep Current. • AlgOR • free technical support (phone/fax/e-mail). • free lifetime software update via Web site.

  • Page 31: Labprog

    LabProg+ LabProg+...

  • Page 32: Introduction

    LabProg+ the ability to handle almost every programmable device in DIL package up to 48 pins without any adapters and/or family modules. This design philosophy allows ELNEC to easily add new devices to the device list, giving you the freedom to implement the optimum device in your designs.
  • Page 33 LabProg+ to handle any PLCC44 target device in the current device list. Most devices with more than 48 pins require a simple adapter usually available from ELNEC or easily built by the user from information provided in the file "adapters.txt"...
  • Page 34 ELNEC s. r. o. control. With our prompt service new devices can be added to the current list within hours! Advanced design, including protection circuits, original brand components and careful manufacturing allows us to provide a three-year warranty on parts and labor for the LabProg+...

  • Page 35: Labprog+ Elements

    LabProg+ LabProg+ elements • 48 pin ZIF (Zero Insertion Force) socket ‚ LED indicator power/sleep ƒ LED indicators for work result „ YES! Button … Connector for PC <-> LabProg+ communication cable † Power supply connector Power supply connector Note: When the LabProg+ programmer isn't active, control program switch the programmer into "sleep mode".

  • Page 36: Connecting Labprog+ To The Pc

    ELNEC s. r. o. Connecting LabProg+ to the PC Switch off PC and programmer. Insert the communication cable included with your LabProg+ programmer package to a free printer port on your PC. If your computer is equipped with only one printer port, substitute the programmer cable for the printer cable.
  • Page 37 LabProg+ Caution! If you don't want to switch off your PC when connecting the LabProg+, proceed as follows: • When connecting the programmer to the PC: FIRST insert the communications cable and THEN the power-supply connector. • When disconnecting the programmer from the PC: FIRST disconnect the power-supply connector and THEN the communication cable.

  • Page 38: Selftest And Calibration

    ELNEC s. r. o. Selftest and Calibration If you feel that your programmer does not react according to your expectation, please run the programmer selftest using Diagnostic POD, enclosed with the standard delivery package. For optimal results with programmer we recommend you undertake every 6 months, an extended test and to check the calibration.

  • Page 39: Technical Specification

    LabProg+ Technical specification Socket, pin drivers and DACs • 48-pin DIL ZIF (Zero Insertion Force) socket accepts both 300/600 mil devices up to 48-pin • Three D/A converters for VCCP, VPP1, and VPP2, with controllable rise and fall time and current limitation •...
  • Page 40 ELNEC s. r. o. Package support • package support includes DIP, PLCC, SDIP, SOIC, PSOP, TSOP, TQFP and other (ask for package converters) • support all devices in DIP with default ZIF-48 socket • support PLCC28, PLCC32 and PLCC44 with universal adapter (optional accessory, to be ordered separately) •...
  • Page 41 LabProg+ PC system requirements See section Introduction/ PC requirements General • operating voltage 12..15V AC/max.1A (adapter 220VAC/12VAC included in package) • power consumption - max. 12W in active mode, approx. 1W sleep mode • dimensions 275x157x47 mm • weight (without external adapter) 1.5 kg •...

  • Page 43: Preprom-02Alv

    PREPROM-02aLV PREPROM-02aLV...

  • Page 44: Introduction

    ELNEC s. r. o. Introduction PREPROM-02aLV is a small and powerful EPROM, EEPROM, Flash EPROM and serial EEPROM programmer and static RAM tester, designed for professional mobile applications. In addition, PREPROM-02aLV programmer with auxiliary modules support also microprocessors (MCS48, MCS51, PICmicro, AVR), GALs, etc.
  • Page 45 PREPROM-02aLV The PREPROM-02aLV can make for use of DIL to PLCC, SOIC, PSOP socket converters. Taking into consideration the PREPROM-02aLV programmer design, protective circuits, and the components used, the manufacturer is able to provide a three-year warranty on parts and labor for the programmer (limited 25,000-cycle warranty on the ZIF socket).

  • Page 46: Preprom-02Alv Diagram

    ELNEC s. r. o. PREPROM-02aLV diagram • 32 pin ZIF socket ‚ LED power/sleep ƒ LED, which indicate work result „ YES! button … communication connector, for PC ó PREPROM-02aLV cable connection † connector for power supply connection Note: Due to low power consumption of PREPROM-02aLV in...

  • Page 47: Connecting Preprom-02Alv Programmer To Pc

    PREPROM-02aLV Connecting PREPROM-02aLV programmer to PC Switch off the PC and programmer. Insert the connection cable, included in the PREPROM-02aLV programmer delivery, to the free printer port of PC. If your computer is equipped with only one printer port, substitute the programmer cable for the printer cable.
  • Page 48 ELNEC s. r. o. Problems related to the PREPROM-02aLV ó PC interconnection, and their removing If you have any problems with PREPROM-02aLV ó PC interconnection, see section Common notes please. Note for laptop and PREPROM-02aLV users Since the PREPROM-02aLV programmer is supplied with 12V, notebook and/or laptop users may operate their PREPROMs- 02aLV everywhere this voltage is available, e.g.

  • Page 49: Selftest And Calibration

    PREPROM-02aLV Selftest and calibration If you have feeling, that your programmer doesn’t behave according to yours expectations (but at least every 3 month), please run PREPROM-02aLV selftest using Diagnostic POD, that contains standard programmer delivery. For optimal fruit of work with PREPROM-02aLV programmer is recommended every 6 months (no more) to make extended test and check the calibration.

  • Page 50: Preprom-02Alv Specification

    ELNEC s. r. o. PREPROM-02aLV specification Socket, pin drivers and DACs • 32-pin DIL ZIF (Zero Insertion Force) socket accepts both 300/600 mil devices up to 32-pin • two D/A converters for VCCP and VPP, with controllable rise/fall time and current limitation •...
  • Page 51 PREPROM-02aLV Device operations • standard: • automatic ID-based selection of EPROM/Flash EPROM • blank check • read • program • verify • erase • configuration and security bit program • illegal bit test • security: • contact check • ID byte check •...
  • Page 52 ELNEC s. r. o. Package included • PREPROM-02aLV programmer • 1.8m (6 ft.) connecting cable PREPROM-02aLV to (IBM) PC • wall plug adapter 220V/50Hz to 12V DC • diagnostic POD, that enable programmer's selftest • diskette with control program • user manual •...

  • Page 53: 51&Avrprog

    51&AVRprog 51&AVRprog...

  • Page 54: Introduction

    ELNEC s. r. o. Introduction 51&AVRprog is little and powerful portable programmer for MCS51 series and Atmel AVR microcontrollers. 51&AVRprog enables also programming serial EEPROM with interface types IIC (24Cxx), Microwire (93Cxx) and SPI (25Cxx). The programmer is equipped by DIL ZIF 40pin socket. The quality of programmer is completed by comfortable control program.

  • Page 55: Connecting 51&Avrprog Programmer To Pc

    51&AVRprog Connecting 51&AVRprog programmer to PC Switch off the PC and programmer. Insert the connection cable, included in the 51&AVRprog programmer delivery, to the free printer port of PC. If your computer is equipped with only one printer port, substitute the programmer cable for the printer cable.
  • Page 56 ELNEC s. r. o. (interrupted cable...). Moreover, an device is usually destroyed in the programming mode due to forced interruption of the control program run (Reset or switching the computer off) due to removing the connecting cable, or unplugging the programmed device from the ZIF socket.

  • Page 57: 51&Avrprog Specification

    51&AVRprog 51&AVRprog specification Socket, pin drivers and DACs • 40-pin DIL ZIF (Zero Insertion Force) socket accepts both 300/600 mil devices up to 40-pin • TTL driver provides H, L and read for all pins Device support • microcontrollers 51 series: 87Cxxx, 87LVxx, 89Cxxx, 89Sxxx, 89LVxxx series from Atmel, Intel, Philips, ...
  • Page 58 ELNEC s. r. o. PC system requirements See section Introduction/ PC requirements General • operating voltage 15÷20V DC/200mA • power consumption 3W max. • dimensions 132x66x30 [mm] (5.2x2.6x1.2 [inch]) • weight (without external adapter) ca. 200g • temperature 5° ÷ 40°C •...

  • Page 59: Pikprog

    PIKprog PIKprog...

  • Page 60: Introduction

    ELNEC s. r. o. Introduction PIKprog is little and powerful portable programmer for Microchip PIC series of microcontrollers. PIKprog enables also programming serial EEPROM with interface types IIC (24Cxx), Microwire (93Cxx) and SPI (25Cxx). The programmer is equipped by DIL ZIF 40pin socket. The quality of programmer is completed by comfortable control program.

  • Page 61: Connecting Pikprog Programmer To Pc

    PIKprog Connecting PIKprog programmer to PC Switch off the PC and programmer. Insert the connection cable, included in the PIKprog programmer delivery, to the free printer port of PC. If your computer is equipped with only one printer port, substitute the programmer cable for the printer cable.
  • Page 62 ELNEC s. r. o. in the programming mode due to forced interruption of the control program run (Reset or switching the computer off) due to removing the connecting cable, or unplugging the programmed device from the ZIF socket. Incorrectly placed...

  • Page 63: Pikprog Specification

    PIKprog PIKprog specification Socket, pin drivers and DACs • 40-pin DIL ZIF (Zero Insertion Force) socket accepts both 300/600 mil devices up to 40-pin • TTL driver provides H, L and read for all pins Device support • microcontrollers Microchip PIC series: 12xxx, 14xxx, 16xxx, 8/16/18/28/40 pins •...
  • Page 64 ELNEC s. r. o. PC system requirements See section Introduction/ PC requirements General • operating voltage 15÷20V DC/max. 200mA • power consumption 3W max. • dimensions 132x66x30 [mm] (5.2x2.6x1.2 [inch]) • weight (without external adapter) ca. 200g • temperature 5° ÷ 40°C •...

  • Page 65: Seeprog

    SEEprog SEEprog...

  • Page 66: Introduction

    ELNEC s. r. o. Introduction SEEprog is universal programmer of all serial EEPROM in 8- pin DIL package. SEEprog programs EEPROM with interface IIC, SPI and Microwire, and also specialty as for example digital thermometers. The programmer supports LV (3.3V) devices too.

  • Page 67: Connecting Seeprog Programmer To Pc

    SEEprog Connecting SEEprog programmer to PC Switch off the PC and programmer. Insert the connection cable, included in the SEEprog programmer delivery, to the free printer port of PC. If your computer is equipped with only one printer port, substitute the programmer cable for the printer cable.
  • Page 68 ELNEC s. r. o. situations, for example power failures and PC failure (interrupted cable...). Moreover, an device is usually destroyed in the programming mode due to forced interruption of the control program run (Reset or switching the computer off) due to removing the connecting cable, or unplugging the programmed device from the ZIF socket.

  • Page 69: Seeprog Specifications

    SEEprog SEEprog specifications Socket and control of pins: • DIL/ZIF socket (300mil) • each pin is possible to set in position Low and Pull-up • from each pin is possible to read • support of Low Voltage devices For work with serial EEPROM are used nearest 8 pins to lever, unused pins are not connected.
  • Page 70 ELNEC s. r. o. Package included • SEEprog programmer • 1.3m (4.3 ft.) connecting cable SEEprog to (IBM) PC • wall plug adapter 12V DC/ 500mA, unstabilized (output 15V if load 200mA) • diskette with control program • user manual •...

  • Page 71: Software

    Software Software...

  • Page 72: The Programmer Software

    MS WINDOWS, run Setup program from diskette Setup/Install (Disk 1/2). Programs PG4U.EXE (for DOS) and PG4UW.EXE (for Windows) are common control programs for all ELNEC's programmers. We guarantee running of these programs under all of above mentioned operating systems without any problems.
  • Page 73 Windows environment: double click to icon PG4UW. After start, control program PG4U / PG4UW automatically scan all existing ports and search for the connected any ELNEC's programmer. Program PG4U/PG4UW is common for all the ELNEC's programmers, hence program try to find all supported...
  • Page 74 ELNEC s. r. o. Description of the user screen Windows program PG4UW DOS program PG4U Header bar the name, copyright statement and version of the PG4U/PG4UW the control program Menu bar list of basic functions File window/Filename information on the currently loaded...
  • Page 75 Software Menu selection is carried out in the normal GUI fashion - either by cursor moving plus pressing <Enter>, or by typing the highlighted letter in the wanted menu or - of course - by mouse. Hot-keys are available for even quicker selection of intensely used commands.

  • Page 76: File

    ELNEC s. r. o. File This submenu is used for source files manipulation, settings and viewing directory, changes drives, changes start and finish address of buffer for loading and saving files by binary, MOTOROLA, MOS Technology, Intel (extended) HEX, Tektronix, ASCII space, JEDEC, and POF format.
  • Page 77 Software File / Exit and save Terminate program and exit to the operation system - save settings to INI file.

  • Page 78: Device

    ELNEC s. r. o. Device The functions for a work with selected programmable devices - device select, read data from device, device blank check, device program, device verify and device erase. Device / Select from default devices This window allows selecting the desired type of the device from list of default devices.
  • Page 79 Software a key <Space> as a separation character) and press <Enter> or click OK button. Press a key <Esc> or click Cancel button at any time to cancel device selection without affecting the currently selected device. Selected device is automatically saved to buffer of default devices (max.
  • Page 80 ELNEC s. r. o. device number in a search box (use a key <Space> as a separation character) and press <Enter> or click OK button. Press a key <Esc> or click Cancel button at any time to cancel device selection without affecting the currently selected device.
  • Page 81 Software Device / Device options All settings of this menu are used for programming process, serialization and associated file control. Device / Device options / Operation options All settings of this command are used for programming process control. This is a flexible environment which content items associated with current device and programmer type.
  • Page 82 ELNEC s. r. o. Actual serialization settings for actually selected device are saving to disk along with associated device by File / Exit and save command. When incremental mode is active following actual settings are saved to configuration file: address, size, serial value, incremental step and settings of modes ASCII / BIN, DEC / HEX, LS byte / MS Byte first.
  • Page 83 Software S / N mode S / N mode option defines the form in which serial value has to be written to buffer. Two options are available: • ASCII • ASCII - means the serial number is written to buffer as ASCII string.
  • Page 84 ELNEC s. r. o. File name File name option specifies the file name from which serial addresses and values will be read. The input file for From file serialization must have special format, which is described in From file serialization file format below.
  • Page 85 Software address is 64 bytes. Data bytes are written to buffer from address addr to addr+n. The process of writing particular bytes to buffer is: byte0 to addr byte1 to addr + 1 byte2 to addr + 2 ..byten to addr + n Optional part is delimited from the first data part by character “...
  • Page 86 ELNEC s. r. o. ; this is last line - end of file In the example file six serial values with labels „nav1“, „nav2“, ...“nav6“ are defined. Each value is written to buffer on address $A7890. All values have size 6 bytes. The line with „nav6“...
  • Page 87 Software Failure number of operations which where not successfully completed Total number of all operations Count down informs about Count down activity (Enabled or Disabled) Remains informs about remaining number of device operations to do Successful operation means any device operation of these, which is completed without errors: •...
  • Page 88 ELNEC s. r. o. Device / Read This command allows to read all device or its part into the buffer. The control program reports a finish of this action by write a message to INFO window. The menu command Device / Device options / Operation options allows to set another working area as the standard.
  • Page 89 Software Device / Test This command executes a test with device selected from list of supported devices (e.g. static RAM) on programmers, which support this test. Device / Device info The command provides additional information about the current device - size of device, organization, programming algorithm and a list of programmers (including auxiliary modules), that supported this device.

  • Page 90: Buffer

    ELNEC s. r. o. Buffer This submenu is used for buffer manipulation, block operation, filling a part of buffer with string, erasing, checksum and of course editing and viewing with other items (find and replace string, printing...). Buffer / View/Edit This command is used to view (view mode) or edit (edit mode) data in buffer (for viewing in DUMP mode only).
  • Page 91 Software switch the mode of buffer data view between 8 bit and 16 bit view. It can be also do by mouse clicking on the button to the right of View/Edit mode buffer indicator. This button indicates actual data view mode (8 bit or 16 bit), too. checksum dialog allows to count checksum of selected block of buffer change mode view / edit...
  • Page 92 ELNEC s. r. o. Direction box specifies which way you want to search, starting from the current cursor position (In edit mode). Forward (from the current position or start of buffer to the end of the buffer) is the default. Backward searches toward the beginning.
  • Page 93 Software Note: Characters 0 and 1 immediately changes content of edit area. Buffer / Fill block Selecting this command causes filling selected block of buffer by requested hex (or ASCII) string. Sets start and end block for filling and requested hex or ASCII string. Buffer / Copy block This command is used to copy specified block of data in current buffer on new address.
  • Page 94 ELNEC s. r. o. Byte sum by bytes to "word". CY flag is ignored Word sum by words to "word". CY flag is ignored Byte (CY) sum by bytes to "word". CY flag is added to result. Word (CY) sum by words to "word". CY flag is added to result.
  • Page 95 Software Calculate: Click on the button Calculate starts calculating checksums for selected block in buffer. No writes into the buffer are executed. Calculate & insert: Click on the button Calculate & insert starts calculating checksums for selected block in the buffer and writes the chosen checksum into the buffer on address specified by Insert address.

  • Page 96: Options

    ELNEC s. r. o. Options The Options menu contains commands that let you view and change various default settings. Options / General options General options dialog allows user to control following options of program. Buffer This page contains several options for loading control by any of HEX formats.
  • Page 97 Software File options File options page allows you to choose loading file format recognizing and set file masks. Load file format Use this command for set file-name masks to use as a filter for file listing in File / Save and File / Load file window for all file formats.
  • Page 98 ELNEC s. r. o. Don't save options - don't save options during quiting program and don't ask for saving options. Auto save options - save options during quiting program without asking for saving options. Prompt for save options - program asks user for saving options before quting program.
  • Page 99 Software absence, the communication with the programmer is unreliable, etc.). If automatic establishing communication is selected, then control program sets a maximal communication speed. Port - selects a LPT port, which will be scanned for a requested programmer. If All port is selected, the control program scans all LPT ports, which are available on standard addresses.
  • Page 100 ELNEC s. r. o. is used), which may makes problems at detecting insertion of a new device. List of pins of device is in form: pinA, pinB, pinC..Example: 4,6,17 This list is erased if a new device is selected by Device / Select default or Device / Select device ...

  • Page 101: Diagnostics

    Software Diagnostics This command includes selftest for programmers and IC test. Diagnostics / Selftest Command executes a selftest of current programmer without diagnostic POD. We recommend execute also Diagnostics / Selftest plus of programmer. Diagnostics / Selftest plus Command executes a selftest of current programmer using diagnostic POD, which is included in standard delivery of programmer.

  • Page 102: Help

    ELNEC s. r. o. Help Pressing the <F1> key accesses the Help. When you selecting menu item and press <F1>, you access context-sensitive help. If PG4U / PG4UW is executing an operation with the programmer <F1> generates no response. The following Help items are highlighted: •...

  • Page 103: Common Notes

    Common notes Common notes...

  • Page 104: Software

    ELNEC s. r. o. Software PG4U/PG4UW is common control program for all of the ELNEC programmers. Thus, during work with him its possible to find some items, those refer not to current selected programmer. There is possible to attach to selected file "device associated file"...

  • Page 105: Hardware

    Common notes Hardware Due a large variety of parallel port types, a case may occur when the programmer cannot "get concerted" with the PC. This problem may be shown as none communication between the PC and the programmer, or by unreliable communication. If this behavior occur, try to connect your programmer to some other PCs or other parallel ports near you.

  • Page 106: Other

    Attention to multitasking OS's (WIN 3.11/95/98/NT/2000). There is needful for regular running of control program for any ELNEC programmer, that printer port, on which is programmer connected, must be reserved for this programmer only. Otherwise, any other program must not simultaneously to use (or any way to modify) this printer port.

  • Page 107: Troubleshooting And Warranty

    Troubleshooting and warranty Troubleshooting and warranty...

  • Page 108: Throubleshooting

    Write everything down that you consider to be relevant about the programmer, software and the target device. Send the completed form by mail or fax to ELNEC (fax number in the control program, submenu Info) or to your local dealer.
  • Page 109 Troubleshooting and warranty • If your programmer is diagnosed as defective, consult your local dealer or ELNEC about the pertinent repair center in your country. Please carefully include the following items in the package: • defective product • completed "PROGRAMMER PROBLEM REPORT" form •...

  • Page 110: If You Have An Unsupported Target Device

    (for DOS) or PG4UWARC.EXE (for WIN) and install the new version of the control program. • Contact ELNEC direct, filling up a "Device Problem Report" form following the instructions at the end of this form. We may need detailed data sheets of your target device and, if possible, samples.

  • Page 111: Warranty Terms

    Appendix E of this manual. • Please also see Troubleshooting section. Manufacturer: *: ELNEC s. r. o., Post 5, P. O. Box 22, SK - 08005 Presov, Slovakia (: +42191/77 34 328, 77 31 007, fax 77 32 797 www.elnec.com, elnec@elnec.com...

  • Page 113: Appendix

    Appendix Appendix...

  • Page 115: Appendix A - Programmer Problem Report Form

    Appendix Appendix A - Programmer Problem Report form Please make a copy of this page to A4 or use the A4 form enclosed in standard delivery package. This form can also be found on the enclosed floppy disk and on our Internet site. PROGRAMMER PROBLEM REPORT Example To (if you know name of contact person) Ing.

  • Page 117: Appendix B - Device Problem Report Form

    Appendix Appendix B - Device Problem Report form Please make a copy of this page to A4 or use the A4 form enclosed in standard delivery package. This form can also be found on the enclosed floppy disk and on our Internet site. DEVICE PROBLEM REPORT Example To (if you know name of contact person) Ing.

  • Page 119: Appendix C - Keep-Current Service

    ELNEC ships off the latest version of the programmer software and updated user documentation (Keep-Current package). A Keep-Current service is your task-free guarantee that you are exploiting your ELNEC programmers and doing high quality programming at maximum and with minimal costs.
  • Page 120 ELNEC s. r. o. Why is it important to use the latest version of the control program? • Semiconductor manufacturers continuously introduce new devices with new package types, manufactured by new technologies in order to support the need for flexibility, quality and speed in product design and manufacturing.

  • Page 121: Appendix D - Algor Service

    This service may be used also for requesting new features of the control program. AlgOR process is simple. The user sends to ELNEC a request for additional support for XXX device to the control program (we may ask for up-to-date data sheets and samples, if needed).

  • Page 123: Appendix E - Registration Card

    If the registration card is missing from your standard programmer delivery package please use a copy of the form below and send it to ELNEC. We remind you that without the "Extended warranty" document only the standard 6-month warranty is granted.

  • Page 125: Appendix F - Ce Certifikates

    Appendix Appendix F - CE certifikates F/1 - CE certificate LabProg+ LabProg+ is a new name of LabProg-48LV.
  • Page 126 ELNEC s. r. o. F/2 - CE certificate PREPROM-02aLV...
  • Page 127 Appendix F/3 - CE certificate 51&AVRprog...
  • Page 128 ELNEC s. r. o. F/4 - CE certificate PIKprog...
  • Page 129 Appendix F/5 - CE certificate SEEprog...
