configuration .ini file of Pg4uwMC while program Pg4uwMC is closed. During next start of
application Pg4uwMC the recent Protected mode settings obtained from .ini file are used.
There is one menu command - Options / Protected mode - that allows to use Protected
mode in application Pg4uwMC. After selecting the menu Options / Protected mode, password
dialog appears. User has to enter password twice to confirm the password is correct. After
successful password confirmation program switches to Protected mode.
Protected mode settings are saved to configuration .ini file of Pg4uwMC. During next start of
program Pg4uwMC the Protected mode settings from .ini file are used.
There is also available one special option - Keep "Load project" operation allowed.
The option is set to disable at default - it means the Load project operation button and menu
will be disabled when Protected mode is active.
If the option is enabled (checked), the Load project operation button and menu will be allowed
in Protected mode.
To switch program from Protected mode back to Normal mode, use the menu command
Options / Normal mode. The "Password required" dialog appears. User has to enter the
same password as the password entered during switch to Protected mode.
When Protected mode is active, the label "Protected mode" is visible near the top of Log
window of Pg4uwMC main window.
Note: Sometimes when Protected mode is switched from active state to inactive state
(Normal mode), some commands (for example command "Load project") may remain
disabled. This can be resolved by clicking on button Stop ALL.
Multi-projects
Multi-project is special feature designed to simplify the programming tasks for multichip
devices.
Multichip device is device with two or more independent chips (of the same or various types)
in single package.
Sub-device - an individual part of multichip device. Sub-device is selectable from Pg4uw
device list. Once selected, you can work with respective chip in fully manner. You can define,
test and save the project file for the partial chip.
Master device - a multichip device unit, consists of sub-devices. Master-device is selectable
from Pg4uw device list, too. Once selected, you can use Multi-project Wizard to build-up the
Multi-project file from individual project files and save/load/execute it.
Multi-project file is special file that contains user selected project files. Multi-project file can
include one or more projects. Projects included in Multi-project (file) are also called sub-
projects.
Project file - a special file, that combines buffer data, Device operation options, special
options and some level of safety features. It completely defines the way how to treat with the
device. Once saved, it can be reloaded anytime and the operation can be repeated exactly.
