The commonly used term are also explained in the user's manual to programmer. The special
terms used here are exactly the terms used by manufacturer of respective chip. Please read
the documentation to the chip you want to program for explanation of all used terms.
List of commonly used items:
group Addresses:
device start address (default 0)
device end address (default device size-1)
buffer start address (default 0)
Split
This option allows setting special mode of buffer when programming or reading device. Using
split options is particularly useful when using 8-bit data memory devices in 16-bit or 32-bit
applications.
Following table describes buffer to device and device to buffer data transfer
Split type Device
None Device[ADDR]
Even Device[ADDR]
Odd Device[ADDR]
1./4 Device[ADDR]
2./4 Device[ADDR]
3./4 Device[ADDR]
4./4 Device[ADDR]
Real addressing will be following: (all addresses are hexadecimal)
Split type Device addresses
None 00 01 02 03 04 05
Even 00 01 02 03 04 05
Odd 00 01 02 03 04 05
1./4 00 01 02 03 04 05
2./4 00 01 02 03 04 05
3./4 00 01 02 03 04 05
4./4 00 01 02 03 04 05
Terms explanation:
Access to device address ADDR is written as Device[ADDR].
Access to buffer address ADDR is written as Buffer[ADDR].
ADDR value can be from zero to device size (in bytes).
All addresses are byte oriented addresses.
group Insertion test:
insertion test (default ENABLE)
If enabled, the programmer checks all pins of the programmed chip, if have proper
connection to the ZIF socket (continuity test). The programmer is able to identify the wrong
contact, misinserted chip and also (partially) backinserted chip.
Device ID check error terminates the operation
Programmer provides ID check before each selected action. It compares read ID codes from
device with ID codes defined by device manufacturer. In case of ID error, control program
behaves as follows:
(default none)
Buffer Address assignment
Buffer[ADDR]
Buffer[2*ADDR]
Buffer[1+(2*ADDR)]
Buffer[4*ADDR]
Buffer[1+(4*ADDR)]
Buffer[2+(4*ADDR)]
Buffer[3+(4*ADDR)]
Buffer addresses
00 01 02 03 04 05
00 02 04 06 08 0A
01 03 05 07 09 0B
00 04 08 0C 10 14
01 05 09 0D 11 15
02 06 0A 0E 12 16
03 07 0B 0F 13 17
109
(default ENABLE)
