H/L/read driver
pins 3, 5, 7, 9, 11, 13 of ISP connector
A)
drivers in programmer
H/L
Float
Read
Pull-up/
Pull-down
C)
drivers in programmer
H/L
Float
Read
Pull-up/
Pull-down
C) Connection of pins 15 and 16 when are configured as logical signal needed for ISP
programming
D) E) When pins 15 and 16 are configured as status of LED OK and LED ERROR
D) before first action with desired ISP device
E) after first action with desired ISP device
Notes: When LED OK or LED ERROR ON (shine), this status is presented as logical H, level
of H is 1,8V - 5V depend on H level of desired ISP device.
When LED OK or LED ERROR OFF (not shine), this status is presented as logical L, level of
L is 0V - 0,4V.
The above mentioned values are provided to understand (and also to exactly calculate) the
value of resistors, which isolate (separate) the programmed chip and target system.
Specification of ISP connector pins depends on the device, which you want to program. You
can find it in the control SW for programmer (Pg4uw), menu Device / Device Info (Ctrl+F1).
Be aware, the ISP programming way of respective device must be selected. It is indicated by
(ISP) suffix after name of selected device.
pin of ISP
connector
RA1
RA2
RA3
pins 15, 16 of ISP connector
CC1
pin of ISP
connector
RC1
RC2
RA1 180R, RA2 1k3, RA3 22k,
RB1 10k, RB2 10k,
CC1 1n, RC1 1k3, RC2 22k,
RD1 22k, CE1 1n, RE1 1k3,
35
BeeProg2 / BeeProg+
pin 14 of ISP connector
B)
pin of ISP
drivers in programmer
VCC
connector
RB2
RB1
YES!
GND
D)
pin of ISP
connector
RD1
GND
E)
pin of ISP
connector
CE1
H/L
RE1
