12.2 LEDs

The Gateway UNIGATE
LED (PROFINET) Power
LED Link / Act. P1
LED Link / Act. P2
LED (PROFINET) State
LED Power
LED State
LEDs 1 / 2 / 4 / 8 (Error No. / Select ID) green
12.2.1

LED "(PROFINET) Power"

This LED is connected directly to the supply voltage of the PROFINET-side.
12.2.2

LED "Link / Act. P1"

This LED is directly controlled by the PROFINET-processor and shines when the gateway at Port
1 (X3 P1) is in an operable network (link-pulses are received) and it flickers when network data
traffic takes place.
12.2.3

LED "Link / Act. P2"

This LED is directly controlled by the PROFINET-processor and shines when the gateway at Port
2 (X3 P2) is in an operable network (link-pulses are received) and it flickers when network data
traffic takes place.
12.2.4

LED "(PROFINET) State"

Off
Lights green
Flashes green
Flashes red
12.2.5

LED "Power"

This LED is connected directly to the (optionally also electrically isolated) supply voltage of the
serial interface (RS232/422/485).
12.2.6

LED "State"

Lights green
Flashes green
Flashes green/red
Lights red
Flashes red
12.2.7

LEDs 1 / 2 / 4 / 8 (Error No. / Select ID)

If these 4 LEDs flash and LED "State" simultaneously lights red, the error number is displayed in
binary notation (conversion table, see Annex) in accordance with the table in chapter "Error
handling". Additionally these LEDs are controllable via Script.
29.9.20 Fieldbus-Gateway UNIGATE
®
CL - PROFINET features 10 LEDs with the following significance:
green
green
green
red/green
green
red/green
Waiting for Script command "Bus Start"
Connection with IO-controller available, data exchange active
PROFINET initialized. Waiting for connection with IO-controller
PROFINET flash indication
Controllable via Script
Controllable via Script
Controllable via Script
General Gateway error (see LEDs Error No.), controllable via Script
UNIGATE is in the configuration / test mode, controllable via Script
®
CX C4Map - PROFINET V. 1.0
Hardware ports, switches and LEDs PROFINET
Supply voltage PROFINET (total device)
Ethernet-link pulse found / network data traffic Port 1
Ethernet-link pulse found / network data traffic Port 2
Interface state Profinet
Supply voltage serial interface
User-defined / general Gateway error
User-defined / general Gateway error
