Deutschmann Automation GmbH & Co. KG

11.2.2 Connector supply voltage and DEBUG-interface

Pin assignment X1 (4-pin screw-plug connector, on the bottom side, at the back)
Pin No. Name
1 UB (Pwr)
2 0 V (Pwr)
3 Rx-Debug
4 Tx-Debug
Attention:
The ground for the DEBUG interface is pin 2, 0V (Pwr).
11.2.3 CANopen ®
The plug (labeled: CANopen
the device.
Pin assignment (9-pin D-SUB, plug)
Pin No. Name
1
2 CAN-L
3 CAN-GND
4
5
6
7 CAH-H
8
9

11.2.4 Power supply

The device must be powered with 10-33 VDC, The voltage supply is made through the 4-pole
screw-plug connector at the device's bottom side.
Please note that the devices of the series UNIGATE

11.3 LEDs

The Gateway UNIGATE
LED (Bus) Power
LED (Bus) State
LED Power
LED State
LEDs 1 / 2 / 4 / 8 (Error No. / Select
ID)

11.3.1 LED "(Bus) Power"

This LED is connected directly to the electrically isolated supply voltage of the CANopen
29.9.20 Fieldbus-Gateway UNIGATE
-connector
®
) for the connection to CANopen
®
®
CL - CANopen features 8 LEDs with the following significance:
green
red/green Interface state CANopen
green
red/green User-defined / general Gateway error
green
®
Hardware ports, switches and LEDs CANopen (Mapping)
Function
10..33 V supply voltage / DC
0 V supply voltage / DC
Receive signal Debug
Transmit signal Debug
®
is available on the front side of
Function
Dominant Low
CAN Ground
Dominant High
®
should not be operated with AC voltage.
Supply voltage CANopen
®
Supply voltage serial interface
User-defined / general Gateway error
CX C4Map - PROFINET V. 1.0
®
®
-side.
29
