10.1 Device labeling
Picture 1: Terminal labeling and termination
Picture 2: Front panel: Rotary switches, DIP-switch, LEDs and termination CO
In case the front panel should pop out it does not affect the device's
function or quality. It can be put in again without problems.
23.6.17
®
UNIGATE
fieldbus gateway UNIGATE
Hardware ports, switches and LEDs
®
CM - CANopen V. 1.4
25
