Deutschmann Automation GmbH & Co. KG Commissioning guide
* it doesn't have the form „k, l, m, n", whereas k, l, m and n are numbers between 0 and
999

19.9 PROFINET connection

Connect the device to the PROFINET at the interface labelled "RJ45 PROFINET-IO".

19.10 Connection to the process device

Please also read the manual for the process device when commissioning the process device.

19.11 Shield connection

Earth the top-hat rail onto which the module has been snapped.

19.12 Connecting the supply voltage

Please connect 10..33 DC voltage to the terminals provided for this.

19.13 Project planning

Use any project planning tool for project planning.
If the required GSD file was not supplied with your project planning tool, a sample file can be
found on the Internet (www.deutschmann.com).
®
29.9.20 Fieldbus-Gateway UNIGATE CX C4Map - PROFINET V. 1.0 51
