Hardware ports, switches and LEDs PROFINET

Connector supply voltage and DEBUG-interface

12.1.1.2
Pin assignment X2 (4-pole screw-plug connector, on the bottom side, at the back)
Pin No.
Name
1
UB (Out)
2
0 V (Out)
3
Rx-Debug
4
Tx-Debug
Attention:
The ground for the DEBUG interface is 0V (Pwr).

12.1.1.3 PROFINET-connector

The plugs (labeled: RJ45 PROFINET-IO) for the connection to PROFINET are available on the
bottom side of the device.
Pin assignment X3 P1 (RJ45 up front, i. e. which is located closer to the front panel)
Pin No.
Name
1
TD+
2
TD-
3
RD+
4
5
6
RD-
7
8
Pin assignment X3 P2 (RJ45 at the back, i. e. which is located closer to the DIN-rail)
Pin No.
Name
1
TD+
2
TD-
3
RD+
4
5
6
RD-
7
8

12.1.1.4 Power supply

The device must be powered with 10-33 VDC, The voltage supply is made through the 4-pole
screw-plug connector at the device's bottom side.
Please note that the devices of the series UNIGATE
34
Function
10..33 V supply voltage / DC
0 V supply voltage / DC
Receive signal Debug
Transmit signal Debug
Fieldbus-Gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
Function
Transmission line +
Transmission line -
Receive line +
Receive line -
Function
Transmission line +
Transmission line -
Receive line +
Receive line -
®
should not be operated with AC voltage.
®
CX C4Map - PROFINET V. 1.0
29.9.20
