Introduction
3
Introduction
®
The UNIGATE
CX-PROFINET 2Port CANopen (mapping) module is used to adapt a CANopen
interface to PROFINET networks. The device has 2 PROFINET ports - one port can e.g. B. can
be used as an outgoing PROFINET port. When we talk about PROFINET, the 100 Mb/s variant,
full duplex and switched Ethernet is automatically connected. The protocol of the terminal is
implemented in the UNIGATE® via a script.
The CX-PN-C4Map module essentially consists of the following hardware components:
•
Electrically isolated interface to PROFINET
•
Processor „FIDO 1100"
•
RAM and Flash
•
Serial interfaces RS232 (Service interfaces)
•
Electrically isolated interface to CANopen
•
Debug interfaces (for device configuration)
Conceptual
C4Map stands for CANopen with CANopen (mapping) functionality.
In the further course of this manual, the term "Fieldbus" is frequently used. In
these cases this applies to the PROFINET interface.
10
Fieldbus-Gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
®
CX C4Map - PROFINET V. 1.0
29.9.20
