10 File System

®
The UNIGATE CX-PN 2Port-C4Map has a file system on the PROFINET side that is used by
the integrated FTP server (see chapter 29) and the integrated web server (see chapter 30). Fur-
thermore it's also used by some devices for storing of device parameters.
If necessary the device parameter files can be created and initialized by the UNIGATE
ically. The following table shows an example of the contents of the file system in delivery condi-
tion (contents may vary depending on the device, subject to change without prior notice).
Table 1 File system content at delivery (example)
File
devname.txt
nvdata
deutschmann.css
favicon.ico
index.html
ssi.html
teaser_header.jp
Please note that
• files can not be overwritten or edited on the device. If you want to replace a file with a
modified version, you must delete the file stored on the device first, and write the modified
file again or transfer to the device.
• during a writing procedure, the execution of the firmware will cut out for a few seconds
(depending on the length of the file). The access to the file system is buffered, so the
actual writing access is delayed by several seconds.
It is possible to reformat the file system via FTP. It will lose all data stored in the file system. To
perform the formatting of your command-line please use the FTP client on Microsoft
(Command Prompt -> ftp.exe). Make a connection to the FTP server of the UNIGATE
run the command "del*.*". The string "*.*" is understood as a request by UNIGATE
the file system.
29.9.20 Fieldbus-Gateway UNIGATE
Remark
device name
non-volatile device parameter
device web site
®
CX C4Map - PROFINET V. 1.0
File System
®
automat-
® ®
Windows
®
and then
®
to format
27
