Danfoss VACON 1000 Operating Manual page 130

VACON® 1000
Operating Guide
AC Drive type
VACON1000-
ED-155-066+GAUL
VACON1000-
ED-160-066+GAUL
VACON1000-
ED-180-066+GAUL
VACON1000-
ED-200-066+GAUL
VACON1000-
ED-210-066+GAUL
VACON1000-
ED-215-066+GAUL
VACON1000-
ED-230-066+GAUL
VACON1000-
ED-250-066+GAUL
VACON1000-
ED-265-066+GAUL
VACON1000-
ED-285-066+GAUL
VACON1000-
ED-305-066+GAUL
VACON1000-
ED-325-066+GAUL
VACON1000-
ED-350-066+GAUL
VACON1000-
ED-378-066+GAUL
VACON1000-
ED-408-066+GAUL
VACON1000-
ED-438-066+GAUL
VACON1000-
ED-475-066+GAUL
VACON1000-
ED-515-066+GAUL
VACON1000-
ED-560-066+GAUL
130 | Danfoss A/S © 2021.06
Low overload rating High overload rating
110% (Variable tor- 150% (Constant tor-
que) que)
I [A] P [kVA] I
L HD
155 1770 113
160 1820 117
180 2050 132
200 2280 146
210 2400 154
215 2450 157
230 2620 168
250 2850 183
265 3020 194
285 3250 209
305 3480 223
325 3710 238
350 4000 256
378 4320 277
408 4660 299
438 5000 321
475 5420 348
515 5880 377
560 6400 410
Cabinet dimensions
[A] P [kVA] W [mm]
1290 3010
1330 3010
1500 3010
1660 3010
1760 3010
1790 3010
1920 5410
2090 5410
2210 5410
2380 5410
2540 5410
2720 5410
2920 5810
3160 6810
3410 6810
3660 6810
3970 7010
4300 7010
4680 7610
Specifications
Weight
[kg]
D [mm] H [mm]
1250 2888 6050
1250 2888 6075
1250 2888 6100
1250 2888 6150
1250 2888 6175
1250 2888 6200
1400 2796 8300
1400 2796 8800
1400 2796 9000
1400 2796 9300
1400 2796 9800
1400 2796 10000
1400 2796 10700
1400 2796 11650
1400 2796 12250
1400 2796 13050
1400 2796 13750
1400 2796 14550
1600 2796 15050
AQ363633621020en-000201 / 172F3117
