VACON® 1000
Operating Guide
3.3 System Hardware
The VACON® 1000 medium-voltage drive consists of a controller cabinet, power cell cabinet, transformer cabinet, and junction cabi-
net. Other cabinets can be configured in accordance with customer requirements in the actual application.
There are two types of drive enclosure:
•
Standalone type with current ratings up to 215 A
•
Line-up type with current ratings 215–680 A (IEC ratings up to 11 kV, UL ratings up to 6.9 kV)
A
C
Illustration 1: Standalone System Structure
A
Control cabinet
B
Power cell cabinet
14 | Danfoss A/S © 2021.06
B
D
C
Junction cabinet
D
Transformer cabinet
AQ363633621020en-000201 / 172F3117
Product Overview
