VACON® 1000
Operating Guide
AC Drive type
VACON1000-
ED-438-100+G2CE
VACON1000-
ED-560-100+G2CE
VACON1000-
ED-680-100+G2CE
Table 21: Nominal Voltage 11000 V, 54-pulse, 9 Power Cells per Phase, 50 Hz
AC Drive type
VACON1000-
ED-036-110+G2CE
VACON1000-
ED-050-110+G2CE
VACON1000-
ED-070-110+G2CE
VACON1000-
ED-090-110+G2CE
VACON1000-
ED-100-110+G2CE
VACON1000-
ED-120-110+G2CE
VACON1000-
ED-140-110+G2CE
VACON1000-
ED-150-110+G2CE
VACON1000-
ED-180-110+G2CE
VACON1000-
ED-190-110+G2CE
VACON1000-
ED-215-110+G2CE
VACON1000-
ED-250-110+G2CE
VACON1000-
ED-305-110+G2CE
VACON1000-
ED-350-110+G2CE
118 | Danfoss A/S © 2021.06
Low overload rating High overload rating
110% (Variable torque) 150% (Constant tor-
que)
I [A] P [kVA] I
L HD
438 7580 321
560 9690 410
680 11770 498
Low overload rating High overload rating
110% (Variable torque) 150% (Constant tor-
que)
I [A] P [kVA] I
L HD
36 680 26
50 950 36
70 1330 51
90 1710 66
100 1900 73
120 2280 88
140 2660 102
150 2850 110
180 3420 132
190 3610 139
215 4090 157
250 4760 183
305 5810 223
350 6660 256
Cabinet dimensions
[A] P [kVA] W [mm]
5550 9810
7100 10610
8620 11010
Cabinet dimensions
[A] P [kVA] W [mm]
490 3410
680 3410
970 3410
1250 3910
1390 3910
1670 3910
1940 3910
2090 4660
2510 4660
2640 4660
2990 4660
3480 6810
4240 7010
4870 7010
Specifications
Weight
[kg]
D [mm] H [mm]
1400 2796 18200
1400 2796 21900
1400 2796 25350
Weight
[kg]
D [mm] H [mm]
1250 2796 4400
1250 2796 4800
1250 2796 5200
1250 2888 6550
1250 2888 6850
1250 2888 7150
1250 2888 7550
1250 2888 10600
1250 2888 10900
1250 2888 11200
1250 2888 11500
1400 2796 12950
1400 2796 14750
1400 2796 16750
AQ363633621020en-000201 / 172F3117
