Technical data

Main features
Type(s):
Consumption:
Power supply requirements:
Electrical protection:
Operating temperature (°C):
Material:
Dimensions of the housing:
Weight of the bag:
Display:
Environment:
Storage temperature:
Air humidity:
Degree of protection:
Product certification:
Electromagnetic compatibility:
Standard:
Inputs:
Potentiometric inputs:
4-20 mA inputs:
Digital inputs:
USB inputs:
Outputs:
Relay outputs:
Relay outputs:
Specification(s)
Maximum 12 watts, without metering accessories connected.
90 ... 240VAC 50/60Hz
Fuses 160 mA. Resetting by power interruption
-5 °C ... 45 °C (23 °F ... 113 °F)
ABS or polycarbonate (USA and Canada)
Length: 280 mm Width: 219 mm Height: 156 mm
0.850 kg
5-inch LCD colour screen, resistive touch
-10 °C ... 70 °C (10 °F ... 158 °F)
Max. 90% non-condensing
IP 65
CE
Class B break tests conform to EN61326-1.
Class B break tests conform to the standard EN61326-2-6.
Class B break tests conform to EN55011.
Harmonic tests conform to EN61000-3-2.
Harmonic tests conform to EN61000-3-3.
The interference immunity tests conform to EN61000-4-2.
Interference immunity tests conform to EN61000-4-3.
Interference immunity test EN61000-4-4.
The interference immunity tests conform to EN61000-4-5.
The interference immunity tests conform to EN61000-4-6.
Interference immunity tests conform to EN61000-4-8.
The interference immunity tests conform to EN61000-4-11.
EN 61000 Electromagnetic compatibility (EMC)
EN 61326 Electrical equipment for measuring, control and labora‐
tory use for a standard environment (class B for residential use)
2 inputs
2 insulated inputs
2 non-insulated inputs
4 inputs
USB connector on the front of the box
2 self-fed relay outputs
2 ON/OFF relay outputs
