Assembly and operating instructions
Splash Control Pro 2
Swimming pool controller
EN
A3207
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.
Part number: 981009
Target group: instructed personnel
Version: BA DM 237 11/20 EN
