Setting measuring and control parameters

'Settings' - 'OPTIONS' menu

8.2.1

'Settings' - 'Metering' menu

8.2.2
96
'OPTIONS' menu lets you access the options available in the
The
installation part.
Options for settings
Enable the basic load settings for metering
Enable the setting function of the maximum dosing time
Enable the setting function of the hysteresis alarm threshold
Enable the setting function of the manual metering stop in the event of an alarm
Fig. 93: 'Settings' - 'OPTIONS' menu
'Enable the basic load settings for metering' : Enables the manual
basic load setting for metering.
'Enable the setting function of the maximum dosing time' : Enables
manual setting of the maximum dosing time threshold value.
'Enable the setting function of the hysteresis alarm threshold' :
Enables manual setting of the hysteresis alarm threshold.
'Enable the setting function of the manual metering stop in the
event of an alarm' : Enables complete manual setting of the
metering stop in the event of an alarm.
'Metering' menu lets you set the metering operating mode and
The
the setpoint of the parameters.
Setpoint and control settings
Parameter with assigned capacity
pH value
Temperature
Fig. 94: 'Settings' - 'Metering' menu
The screen shows the configured parameters. You can only con‐
figure metering by pressing an active parameter.
Free chlorine
A3144
A3145
