8.1.2.6 Parameter configuration
Setting measuring and control parameters
The sequence of parameters is totally independent of the
sequence of the sensors. If the
for each sensor' option is enabled, the sequence of the parame‐
ters created corresponds to the sequence in which you have added
and configured your sensors.
Set parameter
Measurements and calculations
pH value
Temperature
Not used
Not used
Fig. 75: 'MEASUREMENTS and CALCULATIONS' configuration
and installation
The screen displays the configured and unused parameters. You
can change the configuration of a parameter already configured by
pressing it or configure it by pressing an unused parameter.
E01 ... E08 parameter identification. The parameters are identified
by their EOx code in the screens.
The selection of the measured variables is directly related to the
sensors installed and configured. The controller only delivers
measurements for the configured sensors.
The controller automatically completes the parameter configuration
fields when selecting the measurements to information from the
first available compatible sensor in its list. You can change this
configuration if you need to.
Measuring and calculation settings
E02 measurement: Free chlorine
Sensor: Free chlorine AI2
Unit: ppm
Decimal: Automatic
Fig. 76: Parameter configuration
The basis of parameter configuration. Depending on the selected
parameter (measured, calculated, compensated...), additional con‐
figuration options are added on the right (Options area).
'Automatically create a parameter
Chlorine
Not used
Not used
Not used
Options area
A3119
A3122
