Communication programming instructions
Modbus reg‐ Number of
ister registers
41507 2
41509 2
41511 2
41551 2
41553 2
41555 2
41557 2
41559 2
41551 2
42001 2
42003 2
42005 2
42007 2
42009 2
42011 2
42013 2
42015 2
42017 2
42019 2
Measuring device
42051 14
Channel
42101 130
42301 130
74
Name Access
param_E7_dosage r
_u
param_E7_alarm_ rw
hoch
param_E7_alarm_ rw
niedrig
param_E8_state rw
param_E8_measur r
e_value
param_E8_Kon‐ rw
trolle_w
param_E8_dosage r
_u
param_E8_alarm_ rw
hoch
param_E8_alarm_ rw
niedrig
sensor_PO1_Wert r
sensor_PO2_Wert r
sensor_AI1_Wert r
sensor_AI2_Wert r
sensor_AI3_Wert r
sensor_AI4_Wert r
sensor_MI1_Wert r
sensor_MI2_Wert r
sensor_KI1_Wert r
sensor_KI2_Wert r
Unit r
param_E1 r
param_E2 r
Format Description
REAL Metering control [1/1]
REAL High alarm value [unit of
measure]
REAL Low alarm value [unit of
measure]
DWORD Compare with Param State
REAL Measured value [unit of
measure]
REAL Control setpoint [unit of
measure]
REAL Metering control [1/1]
REAL High alarm value [unit of
measure]
REAL Low alarm value [unit of
measure]
REAL PI1 sensor measured value
[sensor unit]
REAL PI2 sensor measured value
[sensor unit]
REAL AI1 sensor measured value
[sensor unit]
REAL AI2 sensor measured value
[sensor unit]
REAL AI3 sensor measured value
[sensor unit]
REAL AI4 sensor measured value
[sensor unit]
REAL Measured value of MI1 sensor
[sensor unit]
REAL Measured value of MI2 sensor
[sensor unit]
REAL DIx sensor measured value
[sensor unit]
REAL DIx sensor measured value
[sensor unit]
STRUC‐ Device statuses and value
TURE
STRUC‐ E1 channel statuses and
TURE value
STRUC‐ E2 channel statuses and
TURE value
