Chapter 7 Troubleshooting
7.3

Error Messages

*When the following error messages occur, turn off the power, and turn the power on after the error has been solved.
LCD Display
E 0 1 : P r i n t e r j a m m i n g .
C h e c k t h e m e d i a
s t o c k e r a n d t h e
p r e s s r o l l e r .
E 0 2 : P r i n t e r j a m m i n g .
C h e c k t h e d a n c e r
r o l l e r 1 a n d t h e n
t u r n o f f t h e p o w e r .
E 0 3 : P r i n t e r j a m m i n g .
C h e c k t h e d a n c e r
r o l l e r 2 a n d t h e n
t u r n o f f t h e p o w e r .
E 0 4 : P o s i t i o n e r r o r
T h e s l i d e r m o v e m e n t
w a s b l o c k e d .
T u r n o f f t h e p o w e r .
E 0 5 : R M S s e n s o r e r r o r
C h e c k t h e p r i n t i n g
c o n d i t i o n f o r t h e
s t a r t i n g m a r k .
E 0 6 : R M S s e n s o r e r r o r
C h e c k t h e p r i n t i n g
c o n d i t i o n f o r R M S .
T u r n o f f t h e p o w e r .
E 0 7 : C r o s s c u t t e r
j a m m i n g . C h e c k t h e
c r o s s c u t t e r .
T u r n o f f t h e p o w e r .
E 0 8 : C r o s s c u t m a r k
C a n n o t r e a d t h e
c r o s s c u t m a r k .
E 0 9 : P r i n t d a t a e r r o r
T h e u n k n o w n d a t a w a s
r e c e i v e d .
C h e c k t h e d a t a .
E 1 0 : H e a d t e m p e r a t u r e
L o w t e m p e r a t u r e o r
e r r o r m e a s u r e .
T u r n o f f t h e p o w e r .
E 9 0 : C u t t e r u n i t
c o m m u n i c a t i o n e r r o r .
T u r n o f f t h e p o w e r .
* When this error message occurs while performing copying, pressing the "NEXT" key will display the target number of
copies currently being printed. (This display will continue for as long as "NEXT" is being pressed, and will disappear
once the button is released.)
7-8
Cause
Ribbon Wind-up
Jammed paper
Paper transfer abnormality
Dancer roller setting is lost
Jammed paper
Paper transfer abnormality
Dancer roller setting is lost
Jammed paper
*
Abnormal shuttle stop
Cutter bade stops in progress
Jammed paper
*
Start marks are not read.
*
Registrations are not read.
*
Abnormal cross cut operation.
(Media cannot be cut.)
Seal case paper jam
Tried to cut only the media and
backing sheet (or apply lamination)
*
Cross cut marks are not read.
Print problem, bowing, conveyance
slip.
Data stops in progress
Unrecognizable data is received
Print head error
*
Communication error
Solution
Reset the media (or the ribbon).
Reset the media
Verify dancer roller 1.
Reset the media.
Verify dancer roller 2.
Reset the media, turn on the power once again.
Verify the motor operating state.
Start marks are not read.
Verify the start mark printing state.
Verify the ink ribbon and the media.
Registration marks are not read.
Verify the registration mark printing state.
Verify the ink ribbon and the media.
Clean the cross cutter.
Verify the operating state of cross cut sensors F
and R.
Reset the media.
Cut the backing sheet only.
Reset the media.
Verify the operating state of cross cut mark
sensors.
Verify the DATA.
Turn off the power.
If there are multiple occurrences, please contact
the distributor where you purchased the unit or
your nearest Graphtec vender.
Turn off the power.
If there are multiple occurrences, please contact
the distributor where you purchased the unit or
your nearest Graphtec vender.
