Chapter 4 Menu Operation
4.24 CUTTER CONSUMPTION
It is possible to accumulate the cutter's cutting length and know the criterion for exchanging cutter blades. Use this as a
criterion as cutter blade consumption varies according to the materials being cut and condition settings (cutting force,
etc.).
Confirming the Consumption Level
The consumption level is displayed from the cutter pen's cumulative travel distance.
(1) Press the LOCAL key from the READY status and the below message will display.
P R I N T E R M E N U >
C U T T E R M E N U >
O U T P U T A L L >
(2) Press the F2 key (CUTTER MENU) and the below screen will display.
B L A D E C O N S U M P T I O N >
T O O L U P / D O W N >
O F F S E T F O R C E >
(3) Press the F1 key (BLADE CONSUMPTION), and the below message will display.
B L A D E C O N S U M P T I O N
(4) Press the F3 key (DISPLAY) and the below screen will display.
B L A D E C O N S U M P T I O N
R E T U R N : E S C
Confirm the level of consumption. The consumption level is displayed from the cutter pen's cumulative travel distance.
Press the ESC key to return to the previous screen.
Clearing the Cumulative Distance (Consumption Level)
When replacing the cutter blade, always clear (return to 0) the cumulative distance display. A new cumulative distance
calculation will begin.
(1) Press the LOCAL key from the READY status and the below message will display.
P R I N T E R M E N U >
C U T T E R M E N U >
O U T P U T A L L >
(2) Press the F2 key (CUTTER MENU) and the below screen will display.
B L A D E C O N S U M P T I O N >
T O O L U P / D O W N >
O F F S E T F O R C E >
(3) Press the F1 key (BLADE CONSUMPTION), and the below message will display.
B L A D E C O N S U M P T I O N
4-46
D I S P L A Y >
C L E A R >
0 0 0 %
D I S P L A Y >
C L E A R >
