4.5 OUTPUT ALL

New incoming data is output through the outlet.
Thus, all previously incoming data (including pending data during print and before cut) is output until the final cut and
print process.
(1) Press the LOCAL key from the READY status.
P R I N T E R M E N U >
C U T T E R M E N U >
O U T P U T A L L >
(2) Press the F3 key (OUTPUT ALL) and the following message is displayed.
O U T P U T A L L ?
Y E S : E N T E R N O : E S C
(3) When the ENTER key (YES) is pressed, all incoming data (including pending data during print and before cut) is
output until the final cut and print process.
When the ESC key (NO) is pressed, the display returns to the previous screen.
(4) When all data is output, the display returns to the READY status.
•
•
•
•
When label materials (media) are sent with the FEED key, the labels that are partway through
printing (pending) cannot be completed normally. If the label material (media) partway through
printing need to be completed, carry out the "OUTPUT ALL" operation instead of the FEED key.
When this menu is executed, a large amount of media, ribbon, and laminate are used fun until the
end of the length of the final output process.
When a warning message is displayed while printing, data being printed (on hold) ill not be
completed.
In this situation, the "OUTPUT ALL" function cannot be performed. Please use "Copy" and execute
read-out one more time.
When there is no output data, the following is displayed.
N O D A T A f o r O U T P U T
P r e s s E N T E R ,
t o r e t u r n m e n u .
Y E S : E N T E R
When the ENTER key (YES) is pressed, the display returns to the previous screen.
This menu generates media white space, but it is effective when there is no continuous output data
or when you want to quickly use the completed labels (output).
Chapter 4 Menu Operation
4-7
