Chapter 5 Replacing Consumable Items
(5) Install the separator winder bobbin. Push until there is a clicking sound.
(6) Open the separator suppression unit and pull out the label materials from the separator unit.
Cut the adhesive area of the label materials approximately 100 mm from the posterior end.
Peel the adhesive section of the label materials.
Pull out the adhesive section from deep in the separator suppression unit.
5-26
•
Set-up becomes easy when the label materials are drawn out from the separator section, the
adhesive sections are peeled, and the remaining backing sheet section is passed through the
separator section once more.
•
When setting label materials for use with the separator, set-up becomes easier when the
separator section is also set at the same time.
