Chapter 4 Menu Operation

4.25 TOOL UP / DOWN

A tool to raise and lower tools.
(1) Press the LOCAL key from the READY status and the below message will display.
P R I N T E R M E N U >
C U T T E R M E N U >
O U T P U T A L L >
(2) Press the F2 key (CUTTER MENU) and the below screen will display.
B L A D E C O N S U M P T I O N >
T O O L U P / D O W N >
O F F S E T F O R C E >
(3) Press the F2 key (TOOL UP / DOWN) and the below screen will display.
T O O L U P / D O W N
U P / D O W N :
R E T U R N : E S C
Press the POSITION keys (▲ ▼) (TOOL UP / DOWN) to raise or lower tools.
Press the ESC key to return to the previous screen.
Press the LOCAL key to return to READY status.
4-48
When handling the cutter blades, take full care not to cut your hands.
