4.18 UNIT LENGTH
Switch the display unit of the coordinate value shown on the display to millimeters (mm) or inches (inch).
Length unit switching is reflected in the following items. Other lengths are fixed in millimeters (mm).
• Media size value
• Distance adjustment input value (input is mm unit and standard inch is shown vertically)
• Head adjustment input value
• Position adjustment input value
• m display during printed length value (mm) selection; ft (feet) display during inch selection.
(1) Press the LOCAL key from the READY status and the below message will display.
P R I N T E R M E N U >
C U T T E R M E N U >
O U T P U T A L L >
(2) Press the F1 key (PRINTER MENU) and the below screen will display.
C O P Y >
D A T A C L E A R >
C O N D I T I O N >
1 / 4
(3) Press the NEXT key until the below screen appears.
R E G I S T R A I O N M A R K >
U N I T L E N G T H >
F U N C T I O N S E T T I N G >
3 / 4
(4) Press the F2 key (UNIT LENGTH) and the below message will display.
U N I T L E N G T H
<
S E L E C T :
Y E S : E N T E R N O : E S C
(5) Change "mm" (millimeter) and "inch" (inch) with the POSITION keys (▲ ▼) and program the unit length.
Press ENTER to confirm and return to the previous screen.
Press the ESC key to return to the previous screen.
Press the LOCAL key to return to READY status.
m m >
