Chapter 4 Menu Operation
necessary to correct to direction minus (–).
Each correction value will become a negative value.
(6) Press the F3 key (HEAD 2-X) and enter the correction value for direction x.
H E A D 2 - X
A D J U S T :
Y E S : E N T E R
Change the numerical value (-1.5 to +1.5) with the POSITION keys (▲ ▼) and program the correction value.
Press ENTER to confirm and return to the previous screen.
H E A D 2 P O S I T I O N A D J .
(7) Press the F3 key (HEAD 2-Y) and enter the correction value for direction x.
H E A D 2 - Y
A D J U S T :
Y E S : E N T E R
Change the numerical value (-1.5 to +1.5) with the POSITION keys (▲ ▼) and program the correction value.
Press ENTER to confirm and return to the previous screen.
H E A D 2 P O S I T I O N A D J .
Press the ESC key to return to the previous screen.
Press the LOCAL key to return to READY status.
In order to confirm the printing results following adjustment, print the adjustment pattern one more time.
4-32
< 0 . 0 > m m
N O : E S C
H E A D 2 - X >
H E A D 2 - Y >
< 0 . 0 > m m
N O : E S C
H E A D 2 - X >
H E A D 2 - Y >
