7.2 Troubleshooting Related to Cutting
The printer does not work when the power is on
Symptom
The control panel's READY lamp does
not light.
Nothing appears on the LCD panel.
The control panel's DATA lamp
does not light or flash.
The control panel's READY lamp lights
up, but the printer does not operate.
"E90: Cutter Unit Communication error"
is displayed on the LCD panel.
When an Error Message is Displayed
Symptom
On the LCD panel "E04: Position Error"
is displayed.
Cause
The printer is not being supplied with
power.
The printer is defective.
Data is not being properly transmitted. Verify that the interface cable is
Data remains in the PC's printer driver. After deleting the data that remains in
The printer is defective.
Cause
The load is large, and the current to
the monitor exceeds specifications.
There is something wrong with the cut
materials condition setting.
Something is contacting the tool
carriage.
An external force is added to the tool
carriage during the cut.
The material scraps have entered
the moving parts and degraded
performance.
When this occurs frequently, please contact the distributor where you
purchased the unit or your nearest Graphtec vender.
Chapter 7 Troubleshooting
Solution
Verify that the power cable is properly
plugged into the printer.
Verify that the power switch is ON.
properly plugged into the printer.
the printer driver properties, resend
the data.
Please contact the distributor where
you purchased the unit or your nearest
Graphtec vender.
Solution
Remove whatever is interfering with
the operation, and reconnect the
power.
Reduce the cut speed.
Reduce the cut pressure.
Remove whatever is interfering with
the operation, and reconnect the
power.
Remove whatever is interfering with
the operation, and reconnect the
power.
Remove whatever is interfering with
the operation, and reconnect the
power.
7-5
