Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
Vehicles with battery monitoring control unit - J367- (with start/
stop system and auxiliary heating and additional heating)
– Disconnect the plug -2- from the control unit -3- before con‐
necting to the battery.
– Fit pole terminal (-) with control unit onto the "-" pole of the
battery, see fig., and tighten the fixing nut -1- (6 Nm).
– Fit the plug -3- again onto the control unit.
Vehicles without battery monitoring control unit - J367-
– Fit battery pole terminal of earth line -2- onto negative terminal
of battery and tighten the nut -3- arrow (6 Nm).
Continued for all vehicles:
When the battery is reconnected, perform the following opera‐
tions depending on the vehicle equipment:
♦ Set clock.
♦ Check the power windows ⇒ Maintenance ; Booklet Octavia
III .
♦ Connect the ⇒ Vehicle diagnostic tester, interrogate the event
memory and delete any event entries.
2.4

Checking battery

All the notes and comments to the work sequence for checking
the battery can be found in the Workshop Manual "Electrical Sys‐
tem – General notes" ⇒ Electrical System – General notes; Rep.
gr. 27 .
2.5

Charging battery

– Open the cover of the heat protection sleeve.
– Open the cover -2- and connect the red charging terminal to
the battery plus (+) terminal. -1-.
– On vehicles with a battery monitoring control unit - J367- ,
connect the black terminal of the charger to earthing point
-3-.
All other notes and comments to this chapter can be found in the
Workshop Manual "Electrical system — General notes " ⇒ Elec‐
trical system — General notes; Rep. gr. 27.
4
Rep. gr.27 - Starter, current supply, CCS
