Additional Brake Light; Removing And Installing The High Level Brake Light - Octavia - Skoda Octavia III 2013 Workshop Manual

Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
6

Additional brake light

⇒ "6.1 Removing and installing the high level brake light - Octa‐
via", page 110
⇒ "6.2 Removing and installing the high level brake light - Octavia
Combi", page 111
⇒ "6.3 Removing and installing the high level brake light - Octavia
Combi GreenLine", page 112
6.1 Removing and installing the high level
brake light - Octavia
Removing
– Switch off the ignition and all electrical components.
– Remove the tailgate trim panel ⇒ Body Work; Rep. gr. 70 .
– Unscrew screws -2- (0.8 Nm).
– Release pre-assembly latches -arrows-.
Note
To facilitate releasing the latches, a welding wire ∅ 4 mm must
be used, which is reworked and used as shown.
a = 8 mm
b = 115 mm
c = 120 mm
– Unplug connector -1-.
– Remove high level brake light.
Installing
Installation is carried out in the reverse sequence.
Note
The high level brake light is fitted with LEDs which cannot be re‐
placed individually.
110
Rep. gr.94 - Lights, bulbs, switches - exterior
