Horn; Removing And Installing Horn - Skoda Octavia III 2013 Workshop Manual

5

Horn

⇒ "5.1 Removing and installing horn", page 161
5.1

Removing and installing horn

Caution
The tone pitch of the horn is set at the factory. It is prohibited
to change this setting or to adjust the control screw!
If it is noticed that a screw is adjusted, the guarantee is no
longer valid.
Removing
– Switch off the ignition and all electrical components.
– Remove front bumper ⇒ Body Work; Rep. gr. 63 .
– Screw out the fixing screws -1- (16 Nm).
– Disconnect plug.
– If necessary unscrew nut (12 Nm) and remove holder from
horn.
Installing
Installation is carried out in the reverse sequence.
Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
161
5. Horn
