Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
3 Windscreen wiper and washer sys‐
tem
⇒ "3.1 Fault recognition and fault display, coding", page 68
⇒ "3.2 Removing and installing the wiper arms with wiper blades
and setting their final setting", page 68
⇒ "3.3 Removing and installing wiper motor with linkage",
page 70
⇒ "3.4 Removing and installing Sensor for rain and light detection
G397 ", page 71
⇒ "3.5 Repairing the rain and light detector sensor G397 , Valeo
manufacturer", page 73
3.1 Fault recognition and fault display, cod‐
ing
♦ The wiper motor control unit - J400- and the windscreen wiper
motor - V- are installed as one component and cannot be re‐
placed separately.
The vehicle voltage control unit - J519- , which regulates the
functions of the windscreen wiper and washer system, is equip‐
ped with self-diagnosis which facilitates the fault finding.
Use the ⇒ Vehicle diagnostic tester for troubleshooting and cod‐
ing.
3.2 Removing and installing the wiper arms
with wiper blades and setting their final
setting
Note
If the wiper motor is switched on during work, the front flap must
be closed and the ignition must be switched on, otherwise the
voltage supply of the wiper motor is interrupted.
Special tools and workshop equipment required
♦ Extractor for wiper arms - T10369/1-
Removing
– Switch off the ignition and all electrical components.
– Lever off caps -3- using screwdriver.
68
Rep. gr.92 - Windscreen wash/wipe system
