Removing And Installing The Microphone For The Telephone R38 - Skoda Octavia III 2013 Workshop Manual

Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
– Measure the resistance between the contacts -arrows- under‐
neath the washer with multimeter.
Measured values:
• 10 kΩ - induction plate OK.
• 20 kΩ - short circuit in the aerial
• 30 kΩ - wire break
• 40 kΩ - compensor fault
• 50 kΩ - terminal 30, 15 on the compensor missing
3.6 Removing and installing the microphone
for the telephone - R38-
Removing
– Remove front interior light
⇒ "1.1.1 Removing and installing the front interior light", page
144 .
– Loosen the microphone out of the retaining lugs -arrows- and
remove.
– Disconnect plug.
Installing
Installation is carried out in the reverse sequence.
46
Rep. gr.91 - Communication
