Octavia III 2013 ➤ , Octavia III 2014 ➤
Electrical system - Edition 12.2014
11 - Rear parking aid warning buzzer - H15-
❑ Removing and installing
⇒ "11.4 Removing and installing the rear parking aid warning buzzer H15 ", page 137
11.2 Remove and install parking aid control
unit - J446- or parking aid and park
steering assistant control unit - J791-
Removing
– Switch off the ignition and all electrical components.
– Remove any protective cladding below the driver side dash
panel.
Left-hand drive- the control unit is found on the relay and fuse
holder:
– Unlock the connectors -1- and -2- and remove by tilting out the
clamp.
– Press of catch peg -arrow- and pull the control unit -3- out of
the holder.
Right-hand drive - the control unit is at the bearing bracket/brake
pedal right:
– Remove the storage compartment in the dash panel on the
front passenger side⇒ Body Work; Rep. gr. 70 .
– Remove expanding rivets -2- and remove unit -1-.
– Unlock the connectors -3- and -4- and remove by tilting out the
clamp.
Installing
Installation is carried out in the reverse order. When installing,
observe the following:
If the control unit for the parking aid - J446- is replaced:
– Code the control unit ⇒ Vehicle diagnostic tester
11.3 Remove and install the front parking aid
warning buzzer - H22-
Removing
– Switch off the ignition and all electrical components.
Left-hand drive:
The warning buzzer -1- is located to the side of the fuse holder.
– Remove knee airbag ⇒ Body Work; Rep. gr. 68 .
136
Rep. gr.94 - Lights, bulbs, switches - exterior
