ELECTRIC SYSTEM
Problem
Alternator Noise.
Starter motor does not turn.
Motor runs in only one direction.
Motor runs extremely hot.
Motor runs but with insufficient power,
or with slow line speed.
Motor runs but drum does not rotate.
3-18
Possible Cause
1. Badly worn belt.
2. Pulleys out of alignment.
3. Loose pulley.
4. Worn bearings.
5. Short in rectifier diodes.
1. Open circuit, dirty
connections.
2. Bad starter relay (diesel engines
only).
3. Bad ignition switch.
4. Worn starter motor, bad starter
solenoid, or internal problem in
engine.
5. Dead battery.
6. Parking brake not engaged.
7. Bad neutral start relay.
1. Defective solenoid
solenoid.
2. Defective control switch.
1. Long period of operation.
2. Insufficient battery power.
3. Bad connection.
1. Insufficient battery power.
2. Bad connection.
1. Clutch not engaged.
2. Clutch engaged.
Published 10-21-2010, Control# 198-04
5540F/YB5515 SERVICE MANUAL
1. Replace belt and adjust.
2. Align fan and alternator pulleys.
3. Check for broken key or worn
keyway, if used.Tighten pulley nut.
4. Replace or repair alternator.
5. Replace or repair alternator.
or loose 1. Clean and tighten connections at
battery and starter. Check wiring
and connections between ignition
switch and starter solenoid.
2. Replace starter relay.
3. Replace switch.
4. Repair or replace starter, replace
solenoid, or see engine manual.
5. Recharge or replace battery.
6. Engage parking brake.
7. Replace relay.
or stuck 1. Jar solenoid to free contacts.
Check by applying 12 volts to coil
terminal (should hear an audible
click when energized). Replace
solenoid.
2. Check and replace if necessary.
1. Cooling-off periods are essential
to prevent overheating.
2. Check battery terminal voltage
under load. If 10 volts or less,
replace the battery.
3. Check
corrosion, clean and grease.
1. Check battery terminal voltage
under load. If 10 volts or less,
replace the battery.
2. Check
corrosion, clean and grease.
1. Engage clutch.
2. Disassemble
determine cause and repair.
Solution
battery cables for
battery cables for
the winch to
