PREVENTATIVE MAINTENANCE

Check Swing Gear/Pinion Backlash

1. Remove the cover to expose the swing pinion and ring
gear.
Rotating gears can cause injury. Keep hand clear of rotating
pinion and gear while the mast is rotating. Start the engine
and rotate the mast until the high point on the swing gear is in
alignment with the pinion. The high point is punch-marked on
the mast plate (Figure 5-53).
2. Using a feeler gauge, check the backlash between the
gear and pinion. There should be no clearance between
the swing gear tooth and the pinion tooth. If there is any
clearance, adjust the backlash. See Section 9,
Structurals.
a0097
High Point Punch Marks
Swing Gear Backlash Check
5-28

Replace the Spark Plugs (Gasoline Engine)

Disconnect one spark plug wire at a time and then replace
the old spark plug with a new plug. Correct spark plug as AC
41-932 spark plug. The spark plug gap should be 0.030
inches (0.76 mm). Connect the spark plug wire and then
remove the next wire.

Replacing the In-line Fuel Filter (Dual Fuel Engine)

NOTE:
1. Engage the parking brake and shut off the engine.
2. Disconnect the two clamps and remove the filter.
3. Install a new filter between the hoses and secure it in
place with the two clamps.

2000 Hours of Operation (Yearly)

NOTE:
For additional engine maintenance guidelines, see the
engine manual furnished with this crane.

Replacing the Engine Coolant

1. Open and prop in place the engine compartment cover.
2. BE SURE THE ENGINE IS COOL and follow the cooling
system draining and filling procedures in the Engine
Operation and Maintenance Manual furnished with the
crane.
3. After the coolant is replaced, close the engine
compartment cover.
FIGURE 5-53
Published 10-21-2010, Control# 198-04
5540F/YB5515 SERVICE MANUAL
It is necessary to climb under the crane to change
the fuel filter Be sure engine is shut off, the ignition
key is removed and chock blocks are in place
before climbing under the crane.
You must read and understand the warnings and
basic safety rules, found in Section 1 of this
manual, before performing any operation or
maintenance procedures.
