5540F/YB5515 SERVICE MANUAL
4. Apply a small quantity of Loctite 242 to the threads in the
knurled nut 2 before fitting.
Torque Settings
Item lb ft
2 8-10
Disassembly (Figure 7-73)
1. Carefully remove piston ring seals.
NOTE: If the piston ring seals are excessively worn then
check for burrs or damage on the shaft grooves. If
necessary remove burrs with a fine grade abrasion
paper and oil.
s232720
2. Remove the taper bearing (2, Figure 7-74) using pullers.
s232720
GROVE
TRANSMISSION AND TORQUE CONVERTER
3.
4.
Nm
10-15
s407220
5.
6.
7.
FIGURE 7-73
s407250
8.
FIGURE 7-74
9.
10. Remove the disc spring 10.
Published 10-21-2010, Control# 198-04
Remove the thrust bearing and thrust washers
(3, Figure 7-75).
Withdraw the gear and splined hub assembly 4 with the
needle roller bearing and spacer. Note the position of the
spacer to ensure it is installed correctly on reassembly.
Remove thrust bearing and thrust washers
(5, Figure 7-76).
Remove the clutch friction/counter plates retaining
circlip 6.
Remove pressure (end) plate 7.
Remove the clutch friction/counter
Figure 7-77). Keep them together in sets, DO NOT mix
the plates with those from other clutches.
Remove last counter plate 9.
FIGURE 7-75
7
FIGURE 7-76
plates (8,
7-49
