Table 1-7: Metric Fasteners, Fine Thread, Untreated
M8x1 M10x1 M10x1.25
Grade
0.157 0.197 0.236
29 57 57
8.8
27 53 53
41 81 81
10.9
38 75 75
49 96 96
12.9
45 90 90
Table 1-8: UNC (Course) Thread: Torque Values for
Stainless Steel Fasteners with Oil Lubrication
Size
lb-in
#5 (0.125) 6.9
#8 (0.164)
#10 (0.190)
1/4
5/16 120
3/8 210
7/16 340
1/2
5/8
3/4
NOTE: Stainless steel fasteners tend to gall while being
tightened. To reduce this risk, lubricate the threads
with oil or molybdenum disulfide and torque at low
speeds without interruptions. Do not use excessive
pressure. Impact wrenches are not recommended.
GROVE
Bolt Diameter - Metric
Torque Values (Nm, Maximum/Minimum)
M12x1.5 M14x1.5 M16x1.5
0.315 0.394 0.472
100 160 248
92 147 229
1140 229 348
130 211 322
168 268 418
156 246 386
Torque Value
lb-ft
—
18 —
21 —
68 —
10
17.5
28
— 39
— 74
— 114
