1.1

Product Description

Adept Python Modules

The Adept Python Linear Modules product line consists of precision ball-screw driven
modules that function as single-axis mechanisms, and can also be combined into
numerous two-, three-, and four-axis configurations. Each linear module is available in
different lengths (see
adds a rotational axis to a Python system, providing additional handling options. You can
find drawings for the multiple axis configurations in
Most module configurations are shipped fully assembled, so the user only needs to
connect the controller and any peripherals. This manual describes the different module
and system types, and covers the basic steps of installing a typical system. Refer to
Table 1-2 on page 22
Adept system.
Module Type
L18
L12
L08
LT1

MotionBlox-10 Servo Controller and Amplifier

Each module axis is controlled and powered by its own on-board servo controller and
amplifier, called a MotionBlox-10 (MB-10). Each MB-10 is linked via the IEEE 1394
high-speed serial communication protocol to the Adept SmartController.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction

1-1) and motor mounting configurations. The Theta module
Table
for a list of manuals that provide additional information on your
Table 1-1. Adept Python Modules
Width Height
185 mm 93 mm
125 mm 83 mm
85 mm 68 mm
90 mm 65 mm
Adept Python Modules User's Guide, Rev. E
1
Chapter 5.
Available Lengths
300 to 2000 mm
200 to 1500 mm
100 to 800 mm
With User Flange = 240 mm
Without Flange = 230 mm
15
