3
Set the paper core (sold separately).
counterclockwise.
Attach the Flange A to the roll holder shaft.
Paper core
4
5
* Align the media to the position where you attach the roll paper to the paper core by the tape as
Supplement
For the paper core (sold separately), please
prepare the paper core that have the same
width as the width of the media to be wound.
Flange A
2-34
