4.10
SENSOR OFFSET ADJUST
Adjust the position of the registration mark sensor from the SENSOR OFFSET ADJUST.
Usually, set the setting values of both X and Y to "0.0".
You can adjust the cut position if the cut position is shifted always in the same direction.
Operation
1
MENU screen is displayed.
2
Press the POSITION (
key.
CHANGE SETTINGS screen is displayed.
3
Press the POSITION (
MARK screen is displayed.
4
Press the POSITION (
SENSOR OFFSET ADJUST screen is displayed.
) keys to select "CHANGE
) keys to select "MARK". Then,
) keys to select "SENSOR OFFSET
4-14
