2.11
Select the Tool Conditions
Set the "CUT CONDITION (Tool Condition) No.", "TOOL", "OFFSET", "FORCE", "SPEED", and "ACCEL
(ACCELERATION)".
LCD Display
Cut condition no.
Selecting the Tool Condition No.
Eight settings (1 to 8) as the cutting condition can be stored. Settings can be changed in accordance with the label
material (8 types) to be used.
Operation
1
CUT CONDITION & TEST screen is displayed.
2
Press the POSITION (
CONDITION (The selected item is highlighted.). Then, press
Cond No. selection screen is displayed.
3
Press the POSITION (
setting(CONDITION No.).
Selected condition
Speed
Offset
Tool
Cross cut
Name of selected
condition
) keys to select the CUT
) key and select the
Force
Acceleration
Winding
2-56
