7
Move the label material (media) to the direction of the pin in a state in which the Flange A and the media
Move the label material (media) until it contacts the pin.
Flange A
Media
8
Push the Flange B so that there is no gap between the paper core and Flange B.
Flange B
9
Pin
Flange A
Media
Flange B
2-15
