Remove the roll holder to be used.
When the slitter is not used, or when winding the media which the edges are cut by the slitter, is one set,
set the roll holder corresponding to one set.
When the media to be wound with the slitter is two sets, set the roll holder corresponding to two sets.
Open the winding stocker cover.
Remove the roll holder to be used.
After setting the winding roll holder, go to Step 17.
<When the winding roll holder is used>
1
Remove the ge.
cannot be touched.
Flange A
Flange B
Pin
Roll holder shaft
