Setting Tool Condition

This section will explain the settings for Tool, Offset, Speed, Force and Acceleration.
The tool conditions for cutting label materials are decided in the following 4 items:
• OFFSET
• FORCE
• SPEED
• ACCEL (ACCELERATION)
CAUTION
•
It may result in damaging the cutter blade or the cutting mat if the blade is extended too much. Make sure the blade length is set less
than the thickness of the media.
Tool Conditions (Cutter Blade) for Each Media Type
Refer to the Cutter Blade Manual (supplied with the cutter unit).
Blade Part Nos., Displayed Blade Types, and CUTTER OFFSET Values
Refer to the Cutter Blade Manual (supplied with the cutter unit).
2-58
