4.13

FRAME CUT

Set the frame cut from the "FRAME CUT".
Usually, set to "OFF".
Set whether or not to use the frame cut (outer frame cut).
When setting "FRAME CUT" to "ON", the outer frame is cut in accordance with the specified cutting area.
Supplement : What is the frame cut (outer frame cut).
or paper-based materials). In such the case, you need to be peeled off later manually. The post-processing is much easier by placing
the cut line to the outer frame on the sheet, weeding with the separator unit and cross-cutting it.
* When the frame cut is enabled, the weeding may not be performed in the separator unit.
* If the length of the media feeding direction is 300 mm or greater, the frame cut will be OFF.
Operation
1
MENU screen is displayed.
2
Press the POSITION (
key.
CHANGE SETTINGS screen is displayed.
3
Press the POSITION (
FRAME CUT screen is displayed.
) keys to select "CHANGE
) keys to select "FRAME CUT".
4-22
