Circuit Breaker

Resetting a circuit breaker

To reset any of the circuit breakers located on the left side of the electronics
module, as shown in Figure 7-4, depress the white button until it sets.
Circuit Breakers- The
front breaker protects
the electrical outlets,
the rear breaker
protects the motor
and lights.

Circuit Breaker Specifications

Circuit breaker specifications are shown in Table 7-2, below.
Circuit Breaker Specifications, 100/115 VAC
Cabinet Width (feet)
Motor/Light Breaker Rating,
Motor/Light Breaker, Labconco
Motor/Light Breaker,
Mechanical Products Part #
Outlet Breaker Rating, Amps
Outlet Breaker, Labconco
Outlet Breaker, Mechanical
Amps
1327208
Part #
1600-062-
080-007
1327204
Part #
1600-062-
050-007
Products Part #
Product Service 1-800-522-7658
3 4 5
8 8 12
1327208 1327201
1600-062- 1600-062-
080-007 120-007
5 5 5
1327204 1327204
1600-062- 1600-062-
050-007 050-007
Figure 7-4
Table 7-2
6
12
1327201
1600-062-
120-007
5
1327204
1600-062-
050-007
125
