Manual or Electric Hydraulic Lift Base Stands
These base stands offer infinitely adjustable height between 25.5 and 33.5 inches (648
to 851 mm), giving a cabinet work surface height of 28.0 to 36.0 inches. The height is
adjusted either by a manual (hand crank) or electric pump that drives hydraulic rams in
the legs of the stands. All of the hydraulic stands are equipped with fixed feet, but can
be converted to caster wheels with the addition of Caster Kit #3784000. The base
stands for each cabinet size is listed in Table 3-2 below.
Width Manual Lift Stand #
3' 3780200
4' 3780201
5' 3780203
6' 3780202
Note: When installing the cabinet on the hydraulic lift base stand, ensure that the
hydraulic lines and the electrical cord are clear of any obstructions before installing the
cabinet on the stand or operating the lift system.
SoLo TM Electric Hydraulic Lift Base Stands
These base stands permit the Logic+ to be lowered enough to be transferred through a
standard doorway as low as 78 inches. Casters provide mobility and lock in place. The
SoLo Stands for each Purifier Logic+ series model is listed below.
115V SoLo Stand
#
3' 3780310
4' 3780311
5' 3780312
6' 3780313
Width Base Stand w/Feet Model #
3'
4'
5'
6'
Electric (115V) Lift Stand
#
3780100
3780101
3780106
3780102
230V SoLo 230V SoLo
No. America UK Plug #
Plug #
3780314
3780315
3780316
3780317
Product Service 1-800-522-7658
Table 3-1
3401003
3401004
3401005
3401006
Table 3-2
Electric (230V) Lift Stand
#
3780103
3780104
3780107
3780105
230V SoLo
Schuko Plug
#
3780330 3780334
3780331 3780335
3780332 3780336
3780333 3780337
230V SoLo
China/Australia
Plug #
3780338
3780339
3780340
3780341
53
