Testing A Circuit Breaker; Replacing A Circuit Breaker - Labconco Purifier Logic+ 30132 Technical Manual And Specifications

Circuit Breaker Specifications, 230 VAC
Cabinet Width (feet)
Motor/Light Breaker Rating,
Motor/Light Breaker, Labconco
Motor/Light Breaker,
Mechanical Products Part #
Outlet Breaker Rating, Amps
Outlet Breaker, Labconco
Outlet Breaker, Mechanical

Testing a circuit breaker

Note: If the breaker is tripped (white button is extended), press the reset button
of the breaker. If it does not reset smoothly, the breaker has failed and must be
replaced.
1. With the breaker reset, unplug the Logic+, either at the wall, or at the power
cord inlet at the back of the electronics module, as shown in Figure 9-2.
2. Remove the three 7/16-inch acorn nuts and lock washers that secure the
module.
3. Tip the module on its side to access the breakers.
4. Using a continuity meter, check the continuity (resistance) across the
terminals of the breaker being tested.
5. The resistance across the breaker should not exceed the resistance noted
when the meter probes are connected to each other.

Replacing a circuit breaker

1. Unplug the Logic+, either at the wall, or at the power cord inlet at the back
of the electronics module, as shown in Figure 7-2.
2. Remove the two 7/16-inch acorn nuts and lock washers that secure the
module.
3. Tip the module on its side to access the breakers.
4. Disconnect the wires connected to the breaker terminals.
5. Using a pair of pliers, loosen the chrome ring nut outside of the reset button.
Remove the ring nut, and pull the breaker out of the electronics module.
126
Amps
1327209
Part #
1600-062-
040-007
1327200
Part #
1600-062-
030-007
Products Part #
Product Service 1-800-522-7658
3 4 5
4 4 5
1327209 1327204
1600-062- 1600-062-
040-007 050-007
3 3 3
1327200 1327200
1600-062- 1600-062-
030-007 030-007
6
5
1327204
1600-062-
050-007
3
1327200
1600-062-
030-007
