- Page 1 Please read user’s manual before operating equipment Original Instructions LABCONCO CORPORATION 8811 Prospect Avenue Kansas City, MO 64132 (800) 821-5525 I +1 (816) 333-8811 labconco.com User’s Manual Protector® Benchtop Evidence Drying Cabinets Register this product...
- Page 2 Protector ® Benchtop Evidence Drying Cabinets 2023—Present 3390000 3390001...
- Page 3 Warranty Labconco Corporation provides a warranty to the original buyer for the repair or replacement of parts and reasonable labor as a result of normal and proper use of the equipment with compatible chemicals. Broken glassware and maintenance items, such as filters, gaskets, light bulbs, finishes and lubrication are not warranted.
-
Page 4: Table Of Contents
Table of Contents 1: INTRODUCTION About This Manual Contents Included 2: BEFORE YOU INSTALL Location Requirements Clearance Requirements Electrical Requirements Exhaust Requirements 3: SAFETY PRECAUTIONS Typographical Conventions General Safety Precautions Safety Precautions for this Product 4: INSTALLATION Step 1: Unpacking the EDC Step 2: Preparing the Evidence Drying Cabinet for Operation Initial Operation •... - Page 5 Prefilters HEPA Filters Blower Cabinet Air Intake and Exhaust Ultraviolet (UV) Lamp Safety Precautions 6: PERFORMANCE FEATURES AND SAFETY PRECAUTIONS Fan/UV Light Switch UV Security Lock Filter System Light Shelf Operation Drying in the Cabinet Start-up Wipe-Down Loading Evidence Unloading Evidence Wipe-Down Shutdown 7: MAINTAINING THE CABINET...
- Page 6 8: TROUBLESHOOTING UV Light is dim or flickering Cabinet Blower and/or lights will not turn on UV Light not working Filter System light is on/flickering APPENDIX A: PARTS LIST APPENDIX B: DIMENSIONS APPENDIX C: SPECIFICATIONS APPENDIX D: ACCESSORIES...
-
Page 7: 1: Introduction
1: Introduction Congratulations on the purchase of a Labconco Protector Evidence Drying Cabinet (EDC). The cabinet is designed to protect you, and the room environment from biohazardous aerosols and offensive odors while drying evidence. The Protector Series cabinet is the result of years of experience in manufacturing laboratory equipment, and users like you suggested many of its features to us. -
Page 8: Contents Included
Verify that all of these items are included with the EDC. If you did not receive one or more of the components listed for the cabinet, or if any of the components are damaged, contact Labconco Corporation immediately for further instructions. -
Page 9: 2: Before You Install
2: Before You Install Before you install the product, the site should be prepared for installation. Examine the location where you intend to install it. You must be certain that the area is level and of solid construction. In addition, a dedicated source of electrical power must be located near the installation site. -
Page 10: Electrical Requirements
Electrical Requirements The product models have the following electrical requirements. Typical Operating Current Catalog Number Electrical Circuit Requirements (Amps) 33900-00 115 VAC, 60 Hz, 6A 1 Phase 33900-01 230 VAC, 50/60 Hz, 3A 1 Phase *Electrical Requirements, ‘V’ = VAC (Voltage with alternating current), ‘A’ = Amperes A dedicated outlet with an appropriate circuit breaker should be located as close as possible to the product (6 feet or 1.8 meters maximum). -
Page 11: 3: Safety Precautions
3: Safety Precautions Before unpacking, installing, operating, maintaining, or servicing this equipment, read the following safety warnings and precautions. Avant le déballage, l’installation, le fonctionnement, l’entretien ou la maintenance de cet équipement, lire les avertissements de sécurité et les précautions d’emploi. –... - Page 12 – Air or components that will be very hot. BURN RISK (HIGH TEMPERATURE) Take care not to touch these defined areas. Failure to avoid these areas may result in moderate to severe injury. – Air ambiant ou RISQUE DE BRÛLURE (TEMPÉRATURE ÉLEVÉE) composant devenant très chaud.
-
Page 13: General Safety Precautions
– Do not lift or move this equipment without assistance. LIFTING HAZARD – Ne pas soulever ou déplacer cet équipement sans DANGER DE LEVAGE assistance. – Magnets or magnetic field present. MAGNETIC FIELD IN USE – Présence d'aimants ou de champ CHAMP MAGNETIQUE UTILISE magnétique. -
Page 14: Safety Precautions For This Product
Ne jamais toucher les parties mobiles. Le non-respect de la consigne consistant à éviter les pièces mobiles peut entraîner des blessures graves, la mort ou des dommages matériels. Never misuse this product. Never disable, override, or otherwise bypass safety guards, panels, switches, sensors or alarms. Doing so will result in moderate to serious injury, death, or damage to this product or property. -
Page 15: 4: Installation
4: Installation With the installation site properly prepared, you are ready to unpack and install the Evidence Drying Cabinet (EDC). This section covers how to: • Unpack and move the cabinet. • Install the cabinet. • Connect the electrical supply source. Step 1: Unpacking the EDC The following tools are required to unpack and install the equipment: •... -
Page 16: Step 2: Preparing The Evidence Drying Cabinet For Operation
Note: United States Interstate Commerce Commission rules require that claims be filed with the delivery carrier within fifteen (15) days of delivery. Do not return goods without the prior authorization of Labconco. Unauthorized returns will not be accepted. If the product was damaged in transit, you must file a claim directly with the freight carrier. -
Page 17: Initial Operation
UV light should relight. Turn the UV Security Keylock to the “OFF” position, and the UV light will turn off. If the UV light does not work as described, then call Labconco’s Product Service Department at 1-800-522-7658 or 816-333-8811. -
Page 18: 5: Performance Features & Safety Precautions
5: Performance Features & Safety Precautions The Protector Evidence Drying Cabinet (EDC) operates using the following principles: • Directional airflow. • Prefiltration of large particulates by an inlet prefilter (in the door) and an exhaust prefilter (in the top of the liner). •... -
Page 19: Directional Airflow
Directional Airflow Directional airflow plays a critical role in EDC performance. Air is drawn into the inlet prefilter, located on the bottom of the door(s). The filtered air then flows upwards through the liner, passing over the evidence to be dried. -
Page 20: Optional Evidence Prefilters
99.99% efficient in removing particles 0.3 micron. The HEPA filter media is very fragile. DO NOT touch the media. If you think the media of a HEPA filter is damaged, DO NOT USE THE CABINET. Call Labconco’s Product Service Department at 1-800-522- 7658 or 816-333-8811. -
Page 21: Blower
Note: HEPA Filters are only effective against particulate material. Gases will pass through the filter. Figure 5-2 Polyurethane seal Filter frame Between media pack and filter frame Filter media pack – A continuous sheet of filter media Blower The blower assembly pulls room air into the intake prefilter on the front of the door(s), through the liner and exhaust prefilter, and then forces it through the HEPA and granular activated carbon filter. -
Page 22: Safety Precautions
Avoid puncturing the HEPA filter during installation or normal operation. If you suspect that a HEPA filter has been damaged, DO NOT use the cabinet; contact Labconco at 800-821-5525 or 816-333-8811 for further information. The HEPA filters in the cabinet will gradually accumulate airborne particulate matter from the items placed in the cabinet. - Page 23 Do not operate the cabinet without all of the appropriate filters in place. If an odor is detected coming out of the granular activated carbon, it needs to be replaced. The weight limit for the fold down shelves is 15 lbs (6.8 kg) each, and the floor of the cabinet and lower storage area is 20 lbs (9.1 kg).
-
Page 24: 6: Performance Features And Safety Precautions
6: Performance Features and Safety Precautions Fan/UV Light Switch The cabinet Fan/UV Light switch is located on the upper front of the cabinet, as shown in Figure 6-1. Turning the switch to the “Fan” position starts the blower, drawing air in through the cabinet. -
Page 25: Shelf Operation
Figure 6-1 Shelf Operation The three drying shelves on the left side wall can be positioned horizontally to dry small pieces of evidence, or swung down, against the left side wall of the liner, if needed. To position the shelves in the up (horizontal) position: 1. -
Page 26: Drying In The Cabinet
Drying in the Cabinet Start-up • Turn off UV light and turn the UV Security switch to “OFF”. Remove the key and store it in a safe place. • Ensure the drain strainer is in place. • Turn the switch to “Fan”. •... -
Page 27: Unloading Evidence
Unloading Evidence • Wear a long-sleeved lab coat with knit cuffs and over-the-cuff rubber gloves. Use protective eyewear. Wear a protective mask if appropriate. • Carefully remove objects in the cabinet. Evidence that was considered biohazardous when loaded should be handled as biohazardous. If your protocol required the use of evidence prefilters, remove them now and store them appropriately. -
Page 28: 7: Maintaining The Cabinet
7: Maintaining the Cabinet This section details the maintenance required for optimal operation of the Evidence Drying Cabinet (EDC). Maintenance Safety Precautions The following tools and supplies are required to maintain the equipment: • #2 Phillips Screwdriver • 70% alcohol solution (or other approved surface disinfectant) •... -
Page 29: Routine Maintenance Schedule
The common service operations necessary to maintain the EDC for peak performance are listed below. Routine Maintenance Schedule Maintenance Frequency Activity Weekly Monthly Annually • • • Disinfect interior surfaces (with suitable chemical disinfectant). • • • Clean door and surface of UV lamp with appropriate glass cleaner. -
Page 30: Service Operations
Service Operations Door Evidence Prefilter Replacement: 1. Pull the prefilter frame(s) straight away from the door(s), as shown in Figure 7-1. 2. Wearing appropriate gloves and working on the inside surface of the prefilter frame(s), carefully pull out the Evidence prefilter(s). The Evidence prefilter(s) can now be examined for trace evidence or stored with the evidence in a sealed bag for future reference. -
Page 31: Cabinet Evidence Prefilter Replacement
Cabinet Evidence Prefilter Replacement: 1. Open the cabinet’s glass door(s) and locate the cabinet prefilter frame on the upper right side of the liner. See Figure 7-2. 2. To access the prefilter, loosen the captive thumbscrew until it is released. The front of the prefilter frame will swing down. - Page 32 Granular Activated Carbon and HEPA Filter Replacement: 1. Use an appropriate stepladder to gain access to the top of the EDC and release the two bungee cords securing the granular activated and carbon and HEPA filters, as shown in Figure 7-3. 2.
-
Page 33: Changing The Uv Lamp
Changing the UV Lamp: NOTE: For optimum performance, the UV lamp should be changed on an annual basis. NOTE: The UV lamp and the work area of the cabinet must be thoroughly decontaminated before removing the lamp. 1. Unplug the cabinet and open the door(s). 2. -
Page 34: Resetting A Circuit Breaker
Resetting a Circuit Breaker: To reset any of the circuit breakers located on the top rear of cabinet, depress the white button until it resets. Figure 7-4 Setting the Speed Control: Adjustment of the speed control varies the volume of air drawn through the liner while the unit is operating. - Page 35 Figure 7-6 2. After removing the hole plug, locate the pressure switch dial which can be turned using the same flat head screwdriver. Refer to 7-7 for a visual. Figure 7-6 NOTE: Turning the dial clockwise will increase the threshold for the pressure light to turn on.
-
Page 36: 8: Troubleshooting
8: Troubleshooting Refer to the following table if the cabinet fails to operate properly. If the suggested corrective actions do not solve the problem, contact Labconco for additional assistance. UV Light is dim or flickering:... -
Page 37: Cabinet Blower And/Or Lights Will Not Turn On
Cabinet Blower and/or lights will not turn... -
Page 38: Uv Light Not Working
UV Light not working... -
Page 39: Filter System Light Is On/Flickering
Filter System light is on/flickering... -
Page 40: Appendix A: Parts List
Appendix A: Parts List Table A-1 indicates common parts that may need replacing. Table A-1 Quantity Item Part No. Description (EA per unit) 3872600 Door Prefilter, 3 FT package of 6 EA 3872601 Door Evidence Prefilter, 3FT package of 10 EA 3872700 Cabinet (top) Prefilter, package of 6 EA 3872701... -
Page 41: Appendix B: Dimensions
Appendix B: Dimensions Figure B-1 indicates the product dimensions. All dimensions shown in inches. Figure B-1 Interior Dimensions: 36.0" (914 mm) H x 32.3" (820 mm) W x 26.5" (673 mm) D Interior Dimensions: 56.0" (1422mm) Height x 26.5" (673mm) Deep x “C” Lower Storage Dimensions: 12.4"... -
Page 42: Appendix C: Specifications
Appendix C: Specifications Power Data Table C-1 Model # Requirements Energy Use 3390000 115 VAC, 60 Hz, 6 Amps 100W 3390001 230 VAC, 50/60 Hz, 3 Amps 100W Environmental Conditions • Indoor use only. • Maximum altitude: 6562 feet (2000 meters). •... -
Page 43: Appendix D: Accessories
Appendix D: Accessories Door Evidence Prefilters (# 3951802) Package of 10 each Door Evidence prefilters. Evidence prefilters are single use polyester prefilters to be examined and or retained for trace evidence. Precut to fit the door prefilter frame. 1 lb. (0.5kg). Cabinet Evidence Prefilters (# 3951803) Package of 10 each Cabinet Evidence prefilters. - Page 44 Security Tags (# 3902400) Package of 100 each tamper-evident, labeled tags. Tags irreversibly indicate if the cabinet door has been opened during the drying cycle. 1 lb. (0.5kg). Hanging Clips (# 3869500) Package of 10 each hanging clips, that allow small articles to be hung from the cabinet’s hanger rod or shelf.
